| Management features |
| MIB support |
Y |
| Configuring Location Settings (CLI) |
Yes |
| Web-based management |
Yes |
| Quality of Service (QoS) support |
Yes |
| Switch layer |
L2/L3 |
| Switch type |
Managed |
| Ports & interfaces |
| Console port |
RJ-45/USB Type-C |
| SFP module slots quantity |
4 |
| Installed SFP+ modules quantity |
0 |
| Installed SFP modules quantity |
0 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity |
24 |
| Network |
| Virtual LAN features |
Private VLAN, Voice VLAN |
| VLAN support |
Yes |
| Broadcast storm control |
Yes |
| Head-of-line (HOL) blocking |
Yes |
| Link aggregation |
Yes |
| QinQ implementation |
Selective QinQ |
| Rate limiting |
Yes |
| Spanning tree protocol |
Yes |
| Policy-based routing |
Yes |
| Port mirroring |
Yes |
| Cable types supported |
Cat5e |
| Networking standards |
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3an, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Data transmission |
| Packet buffer memory |
1.5 MB |
| Jumbo frames |
9000 |
| Jumbo frames support |
Yes |
| Number of static routes |
990 |
| Static route |
Yes |
| Number of queues |
8 |
| Switching capacity |
128 Gbit/s |
| MAC address table |
16000 entries |
| Security |
| Authentication |
MAC-based authentication, Web-based authentication |
| Authentication type |
RADIUS, TACACS+ |
| DoS attack prevention |
Yes |
| Queue scheduling algorithms |
Weighted Round Robin (WRR) |
| SSH/SSL support |
Yes |
| Security algorithms |
HTTPS, SNMP, SNMPv2, SNMPv3, SSH, SSH-2 |
| IGMP proxy |
Yes |
| IGMP snooping |
Yes |
| Access Control List (ACL) rules |
1024 |
| Access Control List (ACL) |
Yes |
| DHCP features |
DHCP auto-config, DHCP client, DHCP relay, DHCP server, DHCP snooping |
| Multicast features |
| Multicast support |
Yes |
| Protocols |
| IPv4 & IPv6 features |
ICMPv6, IPv6 SNMP, IPv6 SSH, IPv6 TFTP, IPv6 Telnet |
| GARP VLAN Registration Protocol (GVRP) |
Yes |
| Design |
| Reset button |
Yes |
| Product colour |
Grey |
| Rack mounting |
Yes |
| Performance |
| Mean time between failures (MTBF) |
698220 h |
| Noise level |
34.8 dB |
| Plug and Play |
Yes |
| Flash memory |
512 MB |
| Internal memory |
1000 MB |
| Memory type |
DDR4-SDRAM |
| Processor frequency |
1.4 MHz |
| Built-in processor |
Yes |
| Power |
| Power plug type |
Type C |
| Power consumption (typical) |
40.9 W |
| AC input frequency |
50/60 Hz |
| AC input voltage |
100 - 220 V |
| Power source |
AC |
| Power over Ethernet (PoE) |
| Total Power over Ethernet (PoE) budget |
375 W |
| Power over Ethernet (PoE) ports quantity |
24 |
| Power over Ethernet (PoE) |
Yes |
| Other features |
| Packaging content |
Switch, power cable, USB Type C cable and mounting hardware |
| Operational conditions |
| Heat dissipation |
1548.8 BTU/h |
| Operating temperature (T-T) |
-5 - 50 °C |
| Storage relative humidity (H-H) |
10 - 90% |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage temperature (T-T) |
-25 - 70 °C |
| Operating temperature (T-T) |
-5 - 50 °C |
| Weight & dimensions |
| Weight |
4.6 kg |
| Height |
43.9 mm |
| Depth |
444.5 mm |
| Width |
350 mm |
| Packaging data |
| Package weight |
7.18 kg |
| Package height |
108 mm |
| Package depth |
575.1 mm |
| Package width |
512.1 mm |
| Certificates |
| Certification |
UL (UL 62368), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A |
