Robustel EG5120 5G Edge Gateway Dual SIM Industrial IoT Router

Many factories and remote sites need a reliable way to send data to the cloud, but old routers often drop connections or cannot handle new 5G speeds. When the network fails, production stops and valuable data is lost. The Robustel EG5120 5G Edge Gateway Dual SIM Industrial IoT Router fixes this by giving you fast 5G, backup 4G/LTE and rugged hardware that works in harsh environments.

Robustel EG5120 5G Edge Gateway Dual SIM Industrial IoT Router with Robustel

Imagine a small box that can connect your machines to any cloud service without a wired line. This industrial PC router does exactly that. It supports 5G, 4G/LTE, 3G and 2G, so you always have a network path. It also has two SIM slots, so if one carrier goes down you can switch instantly. Built on the Robustel platform, it gives you secure VPN, firewall and remote management in one compact unit.

Usages

The EG5120 works well in manufacturing lines that need real-time monitoring, in smart farms that rely on sensor data, and in transportation fleets that must report location and status. It can be mounted on a DIN rail in a control cabinet, placed on a wall near a machine, or used as a desktop gateway for field engineers. Any application that requires fast, reliable edge connectivity benefits from this device.

Benefits

• Dual SIM ensures continuous service even if one network fails.
• 5G speed reduces latency for time-critical IoT data.
• Rugged metal case and wide temperature range survive industrial sites.
• Built-in VPN and firewall keep your data safe from attacks.
• Easy remote management lets you update or troubleshoot from anywhere.

Key Features

• Quad-core Cortex-A53 CPU at 1.6 GHz for fast processing.
• 2 GB DDR4 RAM and 16 GB eMMC storage for apps and logs.
• Supports 5G, 4G/LTE, 3G, 2G with four 5G antennas and two LTE antennas.
• Two Mini-SIM slots for carrier redundancy.
• 210/100 Mbps Ethernet ports (WAN + LAN or dual LAN).
• 2RS-232/RS-485 serial ports, configurable for industrial protocols.
• 4 digital I/O (2 DI, 2 DO) with wet-contact capability.
• Optional Wi-Fi (802.11 a/b/g/n/ac, 22 MIMO) and Bluetooth 5.2.
• IP30 enclosure, metal housing, 567 g weight, 49 105 128 mm size.
• Power input 12-48 V DC with surge protection, idle 5 W, max 20 W.
• Remote management via web, CLI, SMS and RCMS.
• Extensive software support: VPN, firewall, NAT, DHCP, SNMP, Edge2Cloud.
