Full Performance in a Small Form Factor Solution
NVIDIA GPUs power the world’s most advanced desktop workstations, providing the visual computing power required by millions of professionals as part of their daily workflow. All phases of the professional workflow, from creating, editing, and viewing 2D and 3D models and video, to working with multiple applications across several displays, benefit from the power that only a discreet GPU solution can provide. NVIDIA entry level professional GPUs provide advanced features and performance far beyond what is available with integrated GPU solutions – all in a low-profile package, enabling deployment in a wide range of small form factor workstations. Step up to the power of an NVIDIA discreet professional GPU.
The NVIDIA Turing architecture provides significant performance improvements with NVIDIA T1000, resulting in more than 50% graphics performance, compared to the previous generation P1000. Ultra-fast GDDR6 graphics memory technology provides twice the memory bandwidth of the previous generation.
Specifications
| Processor |
| Maximum displays per videocard |
4 |
| CUDA cores |
896 |
| CUDA |
Yes |
| Maximum resolution |
7680 x 4320 pixels |
| Graphics processor |
T1000 |
| Graphics processor family |
NVIDIA |
| Memory |
| Memory bandwidth (max) |
160 GB/s |
| Memory bus |
128 bit |
| Graphics card memory type |
GDDR6 |
| Discrete graphics card memory |
4 GB |
| Ports & interfaces |
| DisplayPort version |
1.4 |
| Mini DisplayPorts quantity |
4 |
| Interface type |
PCI Express x16 3.0 |
| Performance |
| HDCP |
Yes |
| OpenGL version |
4.5 |
| Shader model version |
5.1 |
| DirectX version |
12.0 |
| Design |
| Number of slots |
1 |
| Bracket height |
Low-Profile (LP) |
| Number of fans |
1 fan(s) |
| Cooling type |
Active |
| Power |
| Power consumption (max) |
50 W |
| System requirements |
| Linux operating systems supported |
Yes |
| Windows operating systems supported |
Windows 10 |
| Sustainability |
| Sustainability compliance |
Yes |
| Technical details |
| Compliance certificates |
CE, REACH, RoHS |
| Logistics data |
| Harmonized System (HS) code |
84733020 |
