Are you tired of network appliances that are noisy, bulky, and unreliable? Look no further than the Advantech FWA-1112VC, a powerful and compact network appliance that is designed to meet the needs of modern businesses. With its Intel Atom C3558 processor and 4-core fanless design, this appliance is perfect for applications where reliability and performance are critical. Many businesses struggle with network appliances that are difficult to manage and maintain, but the Advantech FWA-1112VC is designed to be easy to use and manage, making it a great solution for businesses of all sizes.
Advantech FWA-1112VC, Intel Atom C3558, 4 Core Fanless Network Appliance
The Advantech FWA-1112VC solves the problem of unreliable and noisy network appliances by providing a compact and powerful solution that is designed to meet the needs of modern businesses. This problem matters to users because it can cause downtime and lost productivity, which can be costly for businesses. The Advantech FWA-1112VC gives a clear solution by providing a reliable and easy-to-use network appliance that is designed to meet the needs of businesses. With its Intel Atom C3558 processor and 4-core fanless design, this appliance is perfect for applications where reliability and performance are critical.
Key Features
- Intel Atom C3558 processor provides high performance and reliability
- 4-core fanless design makes it perfect for applications where noise is a concern
- Compact and rugged design makes it perfect for use in harsh environments
- Easy to use and manage, making it a great solution for businesses of all sizes
- Supports a variety of network protocols, including TCP/IP, HTTP, and FTP
- Provides a high level of security, including support for SSL/TLS and IPsec
- Can be used in a variety of applications, including network security, VPNs, and wireless networks
- Designed to meet the needs of modern businesses, providing a powerful and reliable network appliance
- Supports up to 32GB of RAM, providing plenty of memory for demanding applications
- Provides a variety of connectivity options, including Ethernet, USB, and serial ports
Specifications
| Processor |
|
| PN |
FWA-1112VC-4CA1S |
| CPU |
Intel® Atom® C3558 |
| Core Count |
4C |
| Base Frequency |
2.2GHz |
| TDP |
16W |
| QAT Technology |
Yes |
| BIOS |
AMI Efi 64Mbit |
| Memory |
|
| Technology |
DDR4 2133MHz |
| Socket |
1 x 260-pin SO-DIMM |
| Max. Capacity |
32GB |
| ECC Support |
YES |
| Storage |
|
| M.2 Storage |
1 x m.2280 SATAIII SSD |
| eMMC Storage |
Default not installed; 4GB/8GB/16GB/32GB is optional by project support |
| Network |
|
| Network Controller |
Intel® SoC MAC with 1 x Marvell 88E1543 PHY, 2 x Intel i210-AT |
| Connector |
4 x RJ45 + 2 x 10G/1G SFP+ |
| PoE |
2 x PoE+ up to 30W/port is optional by project support |
| VPD |
Yes |
| SSID |
Yes |
| I/O |
|
| Console |
1 x RJ45 port |
| USB |
2 x USB3.0 Type A port |
| HDMI/VGA |
NA |
| Expansion |
|
| M.2 |
1 x M-key for 2280 SATAIII SSD
1 x B-key for 3042/3052 LTE/5G module
1 x E-key for 2230 Wifi module |
| Mini-PCIe |
NA |
| SIM |
Default 1 x Mini-SIM socket; 2nd Mini SIM socket for the 2nd LTE module is optional by project support |
| TPM |
TPM2.0 on-board |
| LED & Controls |
|
| LED |
2 x Fixed LED: Power, HDD2 x SW defined LED: LTE, LTE&Wifi2 x SFP+ LED: SFP+1, SFP+2 |
| PW on/off Button |
1 x Power Button |
| Power |
|
| Power Type |
ATX mode |
| Watts |
36W |
| Input |
100 ~ 240VAC, 50/60Hz |
| Connector |
DC Jack Lockable |
| Output |
12VDC 3A, 36W |
| PoE Adaptor |
Optionl; PoE is optional by project |
| Environment |
|
| Operating |
(0 ~ 70 °C (32 ~ 158 °F) |
| Non-operating Temperature |
-40 ~ 85 °C (-40 ~ 185 °F) and 40 °C @ 95% RH Non-Condensing |
| Mechanical |
|
| Material |
Iron chassis with aluminum heat-sink |
| Dimensions |
220 x 160 x 44 mm (8.7" x 6.3" x 1.7") |
| Weight |
2.3Kg (5.07lb) |
| Mounting |
Rack Mount, Wall Mount |
| OS / Software |
|
| OS |
Linux |
| SW |
QuickStart Linux Image, Server iManager |
| Others |
|
| IP Rating |
IP40 |
| Certification |
|
| Safety |
UL 62368, CB 60950/62368, CCC |
| EMC |
CE EN55032/EN55024 ClassB, FCC ClassB, AS/NZS CISPR32,
IEC-61000-4-2/61000-4-5, EN 300 386, VCCI 32-1 |
| ROHS |
ROHS, REACH, WEEE |
