| Display |
| Panel type |
TFT |
| Display brightness |
300 cd/m² |
| HD type |
Full HD |
| Touchscreen |
Yes |
| Display resolution |
1920 x 1080 pixels |
| Display diagonal |
81.3 cm (32") |
| Processor |
| Memory clock speeds supported by processor |
1866,2400 MHz |
| Memory types supported by processor |
DDR3L, LPDDR3-SDRAM, LPDDR4-SDRAM |
| Conflict-Free processor |
Yes |
| Maximum internal memory supported by processor |
8 GB |
| Maximum number of PCI Express lanes |
6 |
| PCI Express configurations |
1x2, 1x2+2x1 |
| PCI Express slots version |
2.0 |
| Processor codename |
Apollo Lake |
| Processor lithography |
14 nm |
| Processor operating modes |
64-bit |
| Processor series |
Intel Pentium Processor N4000 Series for Mobile |
| Processor socket |
BGA 1296 |
| Scenario Design Power (SDP) |
4 W |
| Tjunction |
105 °C |
| Thermal Design Power (TDP) |
6 W |
| Processor cache type |
L2 |
| Processor cache |
2 MB |
| Processor frequency |
1.1 GHz |
| Processor boost frequency |
2.5 GHz |
| Processor threads |
4 |
| Processor cores |
4 |
| Processor model |
N4200 |
| Processor family |
Intel® Pentium® |
| Processor manufacturer |
Intel |
| Memory |
| Memory layout (slots x size) |
1 x 4 GB |
| Memory clock speed |
1867 MHz |
| Memory slots type |
SO-DIMM |
| Memory slots |
1 |
| Internal memory type |
DDR3L-SDRAM |
| Internal memory |
4 GB |
| Storage |
| Optical drive type |
No |
| HDD interface |
SATA |
| Number of storage drives supported |
1 |
| Storage media |
HDD |
| Graphics |
| Number of execution units |
18 |
| On-board graphics card ID |
0x5A84 |
| Maximum on-board graphics card memory |
8 GB |
| Number of displays supported (on-board graphics) |
3 |
| On-board graphics card base frequency |
200 MHz |
| On-board graphics card burst frequency |
750 MHz |
| On-board graphics card model |
Intel® HD Graphics 505 |
| On-board graphics card family |
Intel® HD Graphics |
| On-board graphics card |
Yes |
| Discrete graphics card model |
Not available |
| Discrete graphics card |
No |
| Network |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Ethernet LAN |
Yes |
| Ports & interfaces |
| Serial ports quantity |
2 |
| Headphone outputs |
1 |
| Microphone in |
Yes |
| VGA (D-Sub) ports quantity |
1 |
| HDMI ports quantity |
1 |
| Thunderbolt ports quantity |
0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| USB 2.0 ports quantity |
2 |
| Ethernet LAN (RJ-45) ports |
2 |
| Design |
| Product colour |
Black |
| Performance |
| Product type |
All-in-One PC |
| Processor special features |
| CPU configuration (max) |
1 |
| Embedded options available |
No |
| Enhanced Intel SpeedStep Technology |
Yes |
| Execute Disable Bit |
Yes |
| Idle States |
Yes |
| Intel 64 |
Yes |
| Intel Clear Video Technology |
Yes |
| Intel Enhanced Halt State |
Yes |
| Intel Identity Protection Technology version |
1.00 |
| Intel Rapid Storage Technology |
No |
| Intel Secure Boot |
Yes |
| Intel Secure Boot Technology version |
1.00 |
| Intel Secure Key Technology version |
1.00 |
| Intel Small Business Advantage (SBA) version |
0.00 |
| Intel Smart Connect Technology |
No |
| Intel Smart Connect Technology version |
0.00 |
| Intel Smart Response Technology version |
0.00 |
| Intel Stable Image Platform Program (SIPP) |
No |
| Intel Stable Image Platform Program (SIPP) version |
0.00 |
| Intel Trusted Execution Technology |
No |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Intel Virtualization Technology (VT-x) |
Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Intel® AES New Instructions (Intel® AES-NI) |
Yes |
| Intel® Anti-Theft Technology (Intel® AT) |
No |
| Intel® Clear Video HD Technology (Intel® CVT HD) |
Yes |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) |
Yes |
| Intel® High Definition Audio (Intel® HD Audio) |
Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) |
No |
| Intel® Identity Protection Technology (Intel® IPT) |
Yes |
| Intel® InTru™ 3D Technology |
No |
| Intel® Insider™ |
No |
| Intel® OS Guard |
Yes |
| Intel® Quick Sync Video Technology |
Yes |
| Intel® Secure Key |
Yes |
| Intel® Small Business Advantage (Intel® SBA) |
No |
| Intel® Smart Response Technology |
No |
| Intel® Turbo Boost Technology |
No |
| Intel® Wireless Display (Intel® WiDi) |
No |
| Processor ARK ID |
95592 |
| Processor package size |
24 x 31 mm |
| Thermal Monitoring Technologies |
Yes |
| UART |
Yes |
| Power |
| AC adapter output voltage |
12 V |
| AC adapter power |
84 W |
| Weight & dimensions |
| Weight (with stand) |
15 kg |
| Height (with stand) |
455.2 mm |
| Depth (with stand) |
57.6 mm |
| Width (with stand) |
760.8 mm |
| Operational conditions |
| Operating relative humidity (H-H) |
10 - 95% |
| Operating temperature (T-T) |
0 - 40 °C |
| Certificates |
| Certification |
CE, FCC |
| Other features |
| Cabling technology |
10/100/1000Base-T(X) |
| Display included |
Yes |
| Operating temperature (T-T) |
0 - 40 °C |
