Imagine turning a thin laptop into a desktop-class gaming or design machine in minutes. The AOOSTAR AG03 ( OCuLINK and 2 x TB5) Thunderbolt 5 & OCuLink eGPU Dock lets you add a full-size graphics card to any Thunderbolt 5 or OCuLink device. If you are frustrated by low frame rates, slow rendering, or limited screen options, this dock gives you the power you need without buying a new computer.
AOOSTAR AG03 ( OCuLINK and 2 x TB5) Thunderbolt 5 & OCuLink eGPU Dock
Many modern laptops and mini PCs have fast ports but no room for a dedicated GPU. That limits gaming, video editing, and 3-D work. The problem matters because you lose productivity and enjoyment. The AG03 solves it by providing a PCIe 4.0 x4 slot, two Thunderbolt 5 ports and one OCuLink port, so you can plug in a desktop graphics card and get up to 80 Gbps bandwidth. The result is desktop-level performance from a portable device.
Key Features
- PCIe 4.0 4 slot for full-size desktop graphics cards.
- Two Thunderbolt 5 ports with DisplayPort support and up to 27 W output.
- One OCuLink port delivering up to 64 Gbps bandwidth.
- TB5 right port provides 100 W (PD 3.0) or 140 W (PD 3.1) reverse charging.
- 800 W server-grade power supply built into the dock.
- Three 8-pin PCIe connectors allow up to 500 W GPU power.
- Dual-signal booster amplifiers for stable high-speed data.
- Active cooling system with noise level 34-45 dB.
- Compatible with laptops, mini PCs, desktop PCs, and handheld gaming PCs.
- Switch button to toggle Thunderbolt 5 mode easily.
Specifications
| General |
|
| Product |
AOOSTAR AG03 Thunderbolt 5 & OCuLink eGPU Dock |
| Device Type |
External GPU (eGPU) Dock |
| GPU Support |
Full-size desktop PCIe graphics cards |
| PCIe Interface |
PCIe 4.0 ×4 |
| Maximum Bandwidth |
Up to 64 Gbps (OCuLink), Up to 80 Gbps (Thunderbolt 5), PCIe bandwidth up to 7,000 MB/s theoretical |
| Connectivity |
|
| Host Interface |
1 × OCuLink, 2 × Thunderbolt™ 5 (Intel® JHL9480 Controller) |
| Thunderbolt 5 |
2 × TB5 Ports |
| TB5 Left Port |
DisplayPort protocol, Up to 27W power output |
| TB5 Right Port |
eGPU host connection, PD 3.0 100W / PD 3.1 140W reverse charging |
| TB5 Mode Switch |
1 × Switch Button |
| Graphics Support |
|
| PCIe Slot |
1 × PCIe x16 (PCIe 4.0 ×4 electrical) |
| Maximum GPU Power |
Up to 500W |
| GPU Power Connectors |
3 × 8-pin PCIe |
| Signal Enhancement |
Built-in dual-signal booster amplifiers |
| Power |
|
| Built-in Power Supply |
800W Server Power Supply |
| Power Delivery |
Up to 140W USB Power Delivery (PD 3.1) |
| Cooling |
|
| Cooling |
Active Cooling |
| Noise Level |
Background: 34 dB, Standby: 38–41 dB, Full Load: 41–45 dB |
| Compatibility |
|
| Compatible Devices |
Mini PCs, Laptops, Desktop PCs, Handheld Gaming PCs with Thunderbolt™ 5 or OCuLink |
| Recommended Interface |
Thunderbolt™ 5 or OCuLink |
| Package Contents |
|
| In the Box |
AOOSTAR AG03 eGPU Dock, Thunderbolt™ 5 Cable, Power Supply,
2 × Switch Cables (Graphics card not included)
|
