Imagine losing a video call or a smart camera feed because the power flickered for a second. The APC CP12036LI Back-UPS Connect 12Vdc 36W Lithium-Ion Mini Network UPS stops that from happening. It is a small battery pack that keeps your low-voltage devices running when the mains drops. If you rely on security cameras, door locks, or a home office router, a brief outage can mean lost data, missed alerts, or a broken connection. This UPS gives you the safety net you need.
APC CP12036LI Back-UPS Connect 12Vdc 36W Lithium-Ion Mini Network UPS
The main problem is a sudden loss of 12 V power to network devices. When that happens, the device shuts down and may need a reboot or lose stored information. This matters because many home and small-business systems cannot tolerate even a few seconds of downtime. The APC mini UPS detects the loss instantly and supplies clean 12 V power from its lithium-ion battery. The transition is seamless, so your equipment stays online without interruption.
Key Features
- Output: 12 V 5% DC, 36 W capacity.
- One 2.5 mm DC power jack for input and one for output.
- Lithium-ion technology provides 27.75 Wh of energy.
- Run time up to 4 hours at full load.
- Recharge time about 12 hours from empty.
- Operating temperature range 0 C to 40 C.
- Sound level 40 dBA, quiet for indoor use.
- Fuse protection and audible alarm for safety.
- Mercury-free construction meets RoHS standards.
- Includes a 2.6 ft power cable and white housing.
Specifications
| Header |
|
| Product Line |
APC Back-UPS Connect |
| General |
|
| Product Type |
UPS |
| Device Type |
UPS - external |
| Power Device |
|
| Output Connector Qty |
1 |
| Power Provided |
36 W |
| Power Capacity |
36 W |
| Voltage Provided |
DC 12 V |
| Output Voltage |
DC 12 V ±5% |
| Voltage Required |
12 V |
| Input Voltage |
12 V |
| Input Voltage Range |
DC 11.4–12.6 V |
| Input Connectors |
1 × Power DC jack (2.5 mm) |
| Power Output Connectors |
1 × Power DC jack (2.5 mm, UPS) |
| Form Factor |
External |
| Circuit Protection |
Fuse |
| Battery |
|
| Technology |
Lithium-ion |
| Capacity |
27.75 Wh |
| Transfer Time |
0 ms |
| Run Time (Up To) |
4 hours |
| Recharge Time |
12 hours |
| Environmental Parameters |
|
| Operating Temperature |
32 °F to 104 °F (0 °C to 40 °C) |
| Humidity Range |
0–90% (non-condensing) |
| Sound Emission |
40 dBA |
| Dimensions & Weight |
|
| Height |
1 in |
| Width |
3.9 in |
| Depth |
4.3 in |
| Weight |
10.58 oz |
| Shipping Dimensions & Weight |
|
| Shipping Height |
1.4 in |
| Shipping Width |
4.6 in |
| Shipping Depth |
6.4 in |
| Shipping Weight |
12.7 oz |
| Miscellaneous |
|
| Cables Included |
Power cable (2.6 ft) |
| Color Category |
White |
