Outstanding cooling performance through liquid cooling. ARCTIC's Premium Liquid Freezer range offers impressively high performance at moderate prices without the complexity of conventional CPU water coolers. Completely maintenance-free, the all-in-one cooler with various models for smaller and larger cases covers all the most important current CPU sockets.
Specifications
| Performance |
| Operating temperature (T-T) |
0 - 40 °C |
| Fan speed (max) |
2000 RPM |
| Fan speed (min) |
200 RPM |
| Fan static pressure |
1.85 mmH2O |
| Pump motor speed (max) |
2800 RPM |
| Pump motor speed (min) |
800 RPM |
| VRM fan speed (max) |
2500 RPM |
| VRM fan speed (min) |
400 RPM |
| Quantity per pack |
1 pc(s) |
| Pump connector |
4-pin |
| Bearing type |
Fluid Dynamic Bearing (FDB) |
| Pulse-width modulation (PWM) support |
Yes |
| Airflow |
82.91 m³/h |
| Maximum airflow |
48.82 cfm |
| Supported processor sockets |
Intel LGA1851, LGA 1700, Socket AM4, Socket AM5 |
| Fan diameter |
12 cm |
| Type |
All-in-one liquid cooler |
| Suitable location |
Processor |
| Design |
| Fan connector |
4-pin |
| Illumination colour |
Multi |
| LED connector type |
3-pin |
| Illumination LED |
Yes |
| Number of fans |
2 fan(s) |
| Base plate material |
Copper |
| Radiator material |
Aluminum |
| Product colour |
Black |
| Power |
| Fan current |
0.11 A |
| Fan voltage |
12 V |
| LED voltage |
5 V |
| Pump current |
350 mA |
| Pump voltage |
12 V |
| Weight & dimensions |
| Package weight |
1.93 kg |
| Package height |
142 mm |
| Package depth |
294 mm |
| Package width |
171 mm |
| Cable length |
0.04 m |
| Fan dimensions (W x D x H) |
120 x 120 x 25 mm |
| Weight |
1.49 kg |
| Pump height |
6.85 cm |
| Pump depth |
10.8 cm |
| Pump width |
9.1 cm |
| Tube diameter |
1.24 cm |
| Tube inner diameter |
6 mm |
| Tube length |
45 cm |
| Radiator height |
3.8 cm |
| Radiator depth |
27.7 cm |
| Radiator width |
12 cm |
| Packaging content |
| Package type |
Hanging box |
| Other features |
| Airflow |
82.91 m³/h |
| Operating temperature (T-T) |
0 - 40 °C |
| Country of origin |
Hong Kong |
