Imagine a boardroom where every voice is heard and every face is crystal clear, even in a large space. The AudioCodes RXVCam70 4K PTZ Video Conference Camera is built for that need. It captures 4K video and tracks speakers so remote participants never miss a detail. If you have struggled with blurry video, awkward camera angles, or people talking over each other, this camera solves those problems.
AudioCodes RXVCam70 4K PTZ Video Conference Camera 8.42MP 3840x2160 30fps 12x
Large meeting rooms often produce uneven video coverage and make it hard to follow who is speaking. When remote attendees cannot see the presenter, the meeting loses focus and decisions are delayed. The RXVCam70 fixes this by using two 4K lenses, 12x optical zoom, and AI-driven auto framing. It automatically follows the active speaker and adjusts the view to fit the whole group, giving you a smooth, professional experience every time.
Benefits
- Clear 4K video lets you read facial expressions and details without strain.
- AI speaker tracking keeps the current presenter centered, so you never lose focus.
- Auto framing expands or contracts the view to match the number of people in the room.
- Built-in microphone array captures voices up to 8 m, reducing the need for extra mics.
- Simple control via the RX-PAD remote makes setup quick for any user.
Usages
The camera works well in corporate boardrooms, university lecture halls, and training centers where groups range from five to twenty people. It also fits smaller huddle rooms when you need a high-quality view for Teams or Zoom calls. Facilities managers can mount it on the ceiling or wall and control it from a tablet, while IT teams can connect it to the network for plug-and-play operation. Remote support teams can use it to see equipment details during troubleshooting.
Key Features
- Dual 8.42 MP 4K sensors for full-room coverage.
- 12 optical zoom and 16 digital zoom for close-up detail.
- 119 panoramic lens gives a wide field of view.
- 3-mic array with 8 m pickup range for clear audio.
- 30 fps capture at 3840 2160 resolution.
- 0-170 pan and 0-90 tilt for flexible positioning.
- Ethernet (RJ-45) and USB-C connectivity for easy integration.
- Power over AC/DC up to 20 W, with DC-in jack.
- AI auto-framing, speaker tracking, and smart gallery modes.
- Kensington lock slot for secure mounting.
Specifications
| Camera |
| 3D NR (Noise Reduction) |
Yes |
| White balance |
Auto, Indoor, Manual, Outdoor |
| Aperture range (F-F) |
1.8 - 3.6 |
| Signal-to-Noise Ratio (SNR) |
55 dB |
| Minimum illumination |
0.5 lx |
| Focal length range |
4.8 - 57.8 mm |
| Digital zoom |
16x |
| Optical zoom |
12x |
| Zoom capability |
Yes |
| Optical sensor size |
25.4 / 1.8 mm (1 / 1.8") |
| Sensor type |
CMOS |
| Camera type |
Single camera |
| Megapixel (approx.) |
8.42 MP |
| Video |
| Supported graphics resolutions |
320 x 240, 320 x 288 (QVGA), 480 x 270, 640 x 360, 640 x 480 (VGA), 800 x 600 (SVGA), 960 x 540, 1024 x 576 (WSVGA) |
| Video formats supported |
H.264, MJPG, YUV |
| Supported video modes |
360p, 720p, 1080p |
| Resolution at capture speed |
320x240@25fps, 320x240@30fps, 640x360@25fps, 640x360@30fps, 640x480@25fps, 640x480@30fps, 960x540@30fps |
| HD type |
4K Ultra HD |
| Maximum frame rate |
30 fps |
| Maximum video resolution |
3840 x 2160 pixels |
| Design |
| Pan range |
0 - 170° |
| Tilt angle range |
0 - 90° |
| Product colour |
Black |
| Ports & interfaces |
| DC-in jack |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
| Power |
| DC current (max) |
2 A |
| Power consumption (max) |
20 W |
| DC input voltage |
12 V |
| Power source type |
AC, DC |
| Operational conditions |
| Storage temperature (T-T) |
-40 - 60 °C |
| Operating temperature (T-T) |
-10 - 40 °C |
| Audio |
| Microphone pick-up range |
8 m |
| Number of microphones |
3 |
| Built-in microphone |
Yes |
| Packaging content |
| Mounting kit |
Yes |
| Cables included |
LAN (RJ-45), USB |
| Remote control included |
Yes |
| Performance |
| Cable lock slot type |
Kensington |
| Cable lock slot |
Yes |
| Tracking modes |
Presenter mode |
| Auto framing |
Yes |
| Weight & dimensions |
| Weight |
2.3 kg |
| Height |
151.5 mm |
| Depth |
178.4 mm |
| Width |
181 mm |
| Packaging data |
| Package type |
Box |
| Package height |
240 mm |
| Package depth |
295 mm |
| Package width |
245 mm |
