| Performance |
| Certification |
EN 55032 Class A, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, EN 55024, FCC Part 15 Subpart B Class A, ICES-003 Class A, VCCI Class A, RCM AS/NZS CISPR 32 Class A, KCC KN32 Class A, KN35, IEC/EN/UL 60950-1, EN 50121-4, IEC 62236-4, IEC/EN/UL 60950-22, IEC/EN/UL 62368–1,IEC/EN 60529 IP66/IP67, NEMA TS 2 (Subsection 2.2.7-2.2.9), IEC 62262 IK10, ISO 4892-2, EN 50121-4, IEC 62236-4, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-60, IEC 60068-2-78, NEMA 250 Type 4X, NIST SP500-267, EN 60950-1, GS, UL, cUL, CE, FCC, VCCI, CB, KCC, UL-AR |
| Languages support |
Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Korean, Portuguese, Russian |
| Number of languages |
11 |
| Day/night mode |
Yes |
| Infrared (IR) cut-off filter |
Yes |
| Wide Dynamic Range (WDR) |
Yes |
| Preset points |
Yes |
| Tour recording |
Yes |
| PTZ control |
Yes |
| Connectivity technology |
Wired |
| Placement supported |
Indoor & outdoor |
| Type |
IP security camera |
| Design |
| Fog proof |
Yes |
| IK code |
IK10 |
| International Protection (IP) code |
IP66, IP67 |
| Housing material |
Aluminium |
| Product colour |
Black, White |
| Mounting type |
Ceiling/wall |
| Form factor |
Dome |
| Camera |
| Camera shutter speed |
1/11000 - 1/3 s |
| Pan speed |
450 °/sec |
| Pan range |
0 - 360° |
| Tilt speed |
450 °/sec |
| Tilt angle range |
0 - 220° |
| Lens viewing angle, vertical |
38° |
| Lens viewing angle, horizontal |
63.8° |
| Minimum illumination |
0.002 lx |
| Camera tilt control |
Yes |
| Camera pan control |
Yes |
| Image sensor |
| Progressive scan |
Yes |
| Optical sensor size |
25.4 / 2.8 mm (1 / 2.8") |
| Number of sensors |
1 |
| Sensor type |
CMOS |
| Lens system |
| Maximum aperture number |
4.2 |
| Minimum aperture number |
1.6 |
| Auto focus |
Yes |
| Focal length range |
4.25 - 127.5 mm |
| Digital zoom |
12x |
| Optical zoom |
30x |
| Zoom capability |
Yes |
| Number of lenses |
1 |
| Video |
| Back Light Compensation (BLC) |
Yes |
| Bit rate control |
Variable Bit Rate (VBR) |
| Image quality adjustment |
Brightness, Colour depth, Sharpness |
| Privacy masking |
Yes |
| Text caption overlay |
Yes |
| Video streaming |
Yes |
| Frame rate |
60 fps |
| Supported video modes |
720p |
| Supported graphics resolutions |
320 x 180, 1280 x 720 (HD 720) |
| Video compression formats |
AVC, H.264, H.265, HEVC, M-JPEG, MPEG4 |
| Maximum resolution |
1280 x 720 pixels |
| Network |
| Quality of Service (QoS) support |
Yes |
| Streaming method |
Multicast |
| Supported network protocols |
IPv4, IPv6 USGv6, HTTP, HTTPS, SSL/TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP , SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, NTCIP, LLDP |
| Networking standards |
IEEE 802.1x, IEEE 802.3at |
| Ethernet interface type |
Fast Ethernet |
| Ethernet LAN |
Yes |
| Storage |
| Internal memory |
1024 MB |
| Flash memory |
512 MB |
| Compatible memory cards |
SD, SDHC, SDXC |
| Card reader integrated |
Yes |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
1 |
| Security |
| Alert notification type |
E-mail |
| HTTPS encryption |
Yes |
| IP address filtering |
Yes |
| Intelligent Video Surveillance (IVS) system features |
Missing object, Tripwire |
| Video motion detection |
Yes |
| Password protection |
Yes |
| Power |
| Power consumption (max) |
51 W |
| Power consumption (typical) |
14 W |
| AC input voltage |
100-240 V |
| Power source type |
AC, PoE |
| Operational conditions |
| Operating relative humidity (H-H) |
10 - 100% |
| Storage temperature (T-T) |
-40 - 65 °C |
| Weight & dimensions |
| Weight |
3.75 kg |
| Height |
269 mm |
| Depth |
232 mm |
| Width |
232 mm |
| Supplier features |
| Manufacturer |
Axis |
| Packaging content |
| Manual |
Yes |
| Sun shield included |
Yes |
| Number of cameras |
1 |
| Other features |
| Maximum resolution |
1280 x 720 pixels |
