Name: Axis (02101-002), Fast Ethernet PoE Unmanaged Switch
Brand: Axis Communications
SKU: SWHO-130
Price: 179.99 USD
Availability: InStock

Axis (02101-002), Fast Ethernet PoE Unmanaged Switch

In Stock

UK Free Shipping

$179.99 exc. VAT

Description
Documents
Reviews

The palm-sized AXIS D8004 Unmanaged PoE Switch delivers network and power for up to 4 network devices with plug and play installation. Using AXIS D8004 Unmanaged PoE Switch as a central power source simplifies both installation and maintenance. The switch, together with AXIS surveillance cards, is perfect for small systems with few devices and basic video storage requirements. AXIS D8004 Unmanaged PoE Switch is also ideal when it’s not possible to pull multiple cables. If there’s local power available, simply pull one cable with data connection from the core switch or router, and AXIS D8004 Unmanaged PoE Switch can provide Power over Ethernet (PoE) for all 4 products.

Specifications

Management features
Switch type	Unmanaged
Ports & interfaces
Power connector	DC-in jack
Installed SFP+ modules quantity	0
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Basic switching RJ-45 Ethernet ports quantity	4
Network
Ethernet LAN data rates	10,100 Mbit/s
10G support	No
Networking standards	IEEE 802.3af, IEEE 802.3at
Design
LED indicators	Activity, Network, PoE, Power
Housing material	Metal
Product colour	White
Power
Power consumption (max)	62 W
AC input frequency	50 - 60 Hz
AC input voltage	100 - 240 V
Power supply included	Yes
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget	60 W
Power over Ethernet (PoE) power per port	30 W
Power over Ethernet plus (PoE+) ports quantity	4
Power over Ethernet (PoE)	Yes
Operational conditions
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	5 - 95%
Operating relative humidity (H-H)	5 - 95%
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	0 - 50 °C
Weight & dimensions
Weight	172 g
Height	21 mm
Depth	80 mm
Width	90 mm
Packaging content
User guide	Yes
Cables included	AC
Certificates
Certification	EN 55022:2010/55032:2012 + AC : 2013 Class B, EN 55024, EN 61000-3-2, EN 61000-3-3, EN 50581, FCC Part 15 Subpart B Class B, ICES-003 Class B, IEC/EN/UL 60950-1, CE, WEEE, C-Tick/RCM
