| Performance |
| Certification |
EN 55032 Class A, EN 55035, IEC 62236-4, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), VCCI Class A, RCM AS/NZS CISPR 32 Class A, CISPR 35, EAC, EN 50121-4, KS C 9832 Class A, KS C 9835 |
| Languages support |
Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Thai, Turkish, Vietnamese |
| Number of languages |
19 |
| Built-in processor |
Yes |
| Processor model |
ARTPEC-7 |
| Day/night mode |
Yes |
| Infrared (IR) cut-off filter |
Yes |
| Wide Dynamic Range (WDR) |
Yes |
| Tour recording |
Yes |
| Auto-tracking |
Yes |
| PTZ control |
Yes |
| Connectivity technology |
Wired |
| Placement supported |
Outdoor |
| Type |
IP security camera |
| Design |
| IK code |
IK10 |
| International Protection (IP) code |
IP66, IP67 |
| Housing material |
Aluminium, Polycarbonate (PC) |
| Product colour |
White |
| Mounting type |
Wall |
| Camera |
| Camera shutter speed |
1/8500 - 1/5 s |
| Pan speed |
550 °/sec |
| Tilt speed |
500 °/sec |
| Tilt angle range |
-90 - 20° |
| Lens viewing angle, vertical |
34.9° |
| Lens viewing angle, horizontal |
58.5° |
| Minimum illumination |
0.11 lx |
| Camera tilt control |
Yes |
| Camera pan control |
Yes |
| Image sensor |
| Progressive scan |
Yes |
| Optical sensor size |
25.4 / 2 mm (1 / 2") |
| Sensor type |
CMOS |
| Lens system |
| Maximum aperture number |
4.6 |
| Minimum aperture number |
1.36 |
| Auto focus |
Yes |
| Focal length range |
6.91 - 214.64 mm |
| Digital zoom |
12x |
| Optical zoom |
31x |
| Zoom capability |
Yes |
| Night vision |
| Infra-red wavelength |
850 nm |
| LED type |
IR |
| Night vision distance |
200 m |
| Night vision |
Yes |
| Video |
| Privacy masking |
Yes |
| Video streaming |
Yes |
| Frame rate |
25 fps |
| Video recording |
Yes |
| Video compression formats |
H.264, H.265, M-JPEG |
| Maximum resolution |
3840 x 2160 pixels |
| Network |
| Quality of Service (QoS) support |
Yes |
| Supported network protocols |
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS, HTTP/2, TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTCP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, DHCPv4/v6, ARP, SSH, NTCIP, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf) |
| Networking standards |
IEEE 802.1x, IEEE 802.3bt |
| Ethernet interface type |
Gigabit Ethernet |
| Bluetooth |
No |
| Wi-Fi |
No |
| Ethernet LAN |
Yes |
| Storage |
| Internal memory |
2048 MB |
| Flash memory |
512 MB |
| Compatible memory cards |
SD, SDHC, SDXC |
| Card reader integrated |
Yes |
| Built-in HDD |
No |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
1 |
| Security |
| Digest authentication |
Yes |
| HTTPS encryption |
Yes |
| IP address filtering |
Yes |
| Network access storage (NAS) |
Yes |
| Video motion detection |
Yes |
| Password protection |
Yes |
| Power |
| Power consumption (max) |
51 W |
| Power consumption (typical) |
17 W |
| AC input voltage |
100 - 240 V |
| Power source type |
PoE |
| Operational conditions |
| Storage relative humidity (H-H) |
5 - 95% |
| Operating relative humidity (H-H) |
10 - 100% |
| Storage temperature (T-T) |
-40 - 65 °C |
| Operating temperature (T-T) |
-50 - 50 °C |
| Weight & dimensions |
| Weight |
4.8 kg |
| Diameter |
23.9 cm |
| Height |
261 mm |
| Supplier features |
| Manufacturer |
Axis |
| Packaging content |
| Packaging content |
Windows decoder 1-user license, 60 W Midspan (including power cable), IP66 rated network connector, repaint template, paint paper |
| Manual |
Yes |
| Number of cameras |
1 |
| Other features |
| Maximum resolution |
3840 x 2160 pixels |
