Many people worry about empty spots, dark corners, and missed alerts when they protect a building or a yard. Those gaps can let trouble happen without anyone seeing it. When a camera cannot see at night or cannot follow a moving object, you lose confidence in your security system. The Axis 02332-001 Outdoor Digital PTZ IP Camera Wired Multilingual EN Compliant fills those gaps. It gives clear video, smooth pan-tilt-zoom control, and smart alerts so you always know what is happening.
Axis 02332-001 Outdoor Digital PTZ IP Camera Wired Multilingual EN Compliant with Axis
This camera is built for tough outdoor use. It records in 4K, can turn 190 degrees left or right and tilt up to 80 degrees, and it works in total darkness thanks to Lightfinder 2.0. The device also runs deep-learning analytics that tell you when a person or a vehicle appears, so you get instant alerts. If you need a reliable eye on a site that never sleeps, this Axis model is the answer.
Usages
You can mount the camera on a warehouse roof to watch loading bays and stop theft. It works well in parking lots where you need to track cars and catch suspicious moves. Schools benefit from the multilingual menu and audio detection, helping staff react fast. Retail stores use the digital PTZ to follow shoppers and deter shoplifting. City streets get a sturdy, vandal-proof eye that records every detail, day or night.
Benefits
- Clear 4K video lets you see faces and license plates.
- Smart analytics cut false alarms and save your time.
- IP66 and IK10 ratings protect the camera from rain and vandalism.
- Power over Ethernet makes wiring quick and cheap.
- Built-in security stops hackers from stealing your footage.
Key Features
- 8 MP sensor with 3840 2160 maximum resolution.
- Lightfinder 2.0 for bright images in low light.
- Forensic WDR balances bright and dark areas.
- Digital PTZ with 190 pan and 80 tilt range.
- Optimized IR provides clear night vision up to 40 m.
- Deep-learning unit detects humans, vehicles and vehicle types.
- Two-way audio with detection and talk back.
- Supports 12 languages for easy setup.
- H.264 and H.265 compression saves storage space.
- MicroSD slot up to 32 GB for local recording.
Specifications
| Performance |
| Certification |
EN 50121-4, EN 55032 Class A, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), IEC 62236-4, KC KN32 Class A, KC KN35, RCM AS/NZS CISPR 32 Class A, VCCI Class A |
| Languages support |
Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Korean, Polish, Portuguese, Russian |
| Number of languages |
12 |
| Day/night mode |
Yes |
| Infrared (IR) cut-off filter |
Yes |
| Wide Dynamic Range (WDR) |
Yes |
| PTZ modes |
Digital PTZ |
| Connectivity technology |
Wired |
| Placement supported |
Outdoor |
| Type |
IP security camera |
| Design |
| IK code |
IK10 |
| International Protection (IP) code |
IP66 |
| Housing material |
Polycarbonate (PC) |
| Product colour |
White |
| Mounting type |
Ceiling/wall |
| Form factor |
Dome |
| Camera |
| Camera shutter speed |
1/8500 - 1/5 s |
| Pan range |
-190 - 190° |
| Tilt angle range |
-10 - 80° |
| Angle of rotation |
190° |
| Minimum illumination |
0.14 lx |
| Camera tilt control |
Yes |
| Camera pan control |
Yes |
| Image sensor |
| Progressive scan |
Yes |
| Optical sensor size |
25.4 / 1.8 mm (1 / 1.8") |
| Number of sensors |
1 |
| Sensor type |
CMOS |
| Lens system |
| Normal focusing range |
0.5 m |
| Focal length range |
4.3–8.6 |
| Zoom capability |
Yes |
| Number of lenses |
1 |
| Night vision |
| Infra-red wavelength |
850 nm |
| LED type |
IR |
| Night vision distance |
40 m |
| Night vision |
Yes |
| Video |
| Bit rate control |
Variable Bit Rate (VBR) |
| Flip & mirror |
Yes |
| Image quality adjustment |
Brightness, Contrast, Saturation, Sharpness |
| Privacy masking |
Yes |
| Smart IR |
Yes |
| Text caption overlay |
Yes |
| Gain control type |
Auto |
| Video streaming |
Yes |
| Frame rate |
30 fps |
| Video recording |
Yes |
| Video compression formats |
H.264, H.265 |
| Total megapixels |
8 MP |
| Maximum resolution |
3840 x 2160 pixels |
| Audio |
| Audio detection |
Yes |
| Network |
| Quality of Service (QoS) support |
Yes |
| Supported network protocols |
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSa , HTTP/2, TLSa , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, RTSP, RTCP, RTP, SRTP, TCP, UDP, IGMPv1/v2/v3, DHCPv4/v6, ARP, SSH, SIP, LLDP, CDP, MQTT v3.1.1, Syslog, Link-Local address (ZeroConf) |
| Networking standards |
IEEE 802.1x, IEEE 802.3af, IEEE 802.3at |
| Bluetooth |
No |
| Wi-Fi |
No |
| Ethernet LAN |
Yes |
| Storage |
| Internal memory |
2048 MB |
| Flash memory |
8192 MB |
| Compatible memory cards |
MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Card reader integrated |
Yes |
| Built-in HDD |
No |
| Ports & interfaces |
| Terminal block port |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Security |
| Active tampering alarm |
Yes |
| Alert notification type |
E-mail |
| HTTPS encryption |
Yes |
| IP address filtering |
Yes |
| Video motion detection |
Yes |
| Password protection |
Yes |
| Power |
| Power consumption (max) |
11.2 W |
| Power consumption (typical) |
5.5 W |
| Power source type |
PoE |
| Operational conditions |
| Storage relative humidity (H-H) |
5 - 95% |
| Operating relative humidity (H-H) |
10 - 100% |
| Storage temperature (T-T) |
-40 - 65 °C |
| Operating temperature (T-T) |
-40 - 50 °C |
| Weight & dimensions |
| Weight |
900 g |
| Diameter |
14.9 cm |
| Height |
107 mm |
| Supplier features |
| Manufacturer |
Axis |
| Packaging content |
| Manual |
Yes |
| Drilling template included |
Yes |
| Number of cameras |
1 |
| Other features |
| Maximum resolution |
3840 x 2160 pixels |
