| Network Certification |
Tier 1 Carriers: AT&T, UScellular, T-Mobile, Verizon |
| |
CBRS: Part 96 EUD, CAT A and CAT B CPE-CBSD |
| |
Anterix Active B106 |
| |
Southern Linc |
| Availability and Resilience |
Dual-WAN ports (5G & Gigabit Ethernet WAN) |
| |
Load balancing – Maximizing bandwidth of outbound traffic |
| |
Automatic failover and fallback |
| |
Virtual Routing Redundancy Protocol (VRRP) |
| 5G NR |
Sub-6 GHz |
| |
3GPP Rel.16 |
| |
Frequency Range 1 Bands (SA & NSA): n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25,
n26, n28, n29, n30, n38, n40, n41, n48, n66, n70, n71, n77, n78, n79
|
| |
Carrier Aggregation: sub-6 GHz (FDD+FDD, TDD+TDD, FDD+TDD 2CA) |
| |
Channel Bandwidth: Up to 120 MHz |
| |
Modulation: 256QAM DL / 256QAM UL |
| 4G / LTE |
Cat.19 |
| |
FDD & TDD Bands: 1, 2, 3, 4(66), 5(18,19,26), 7, 8, 12(17), 13, 14, 20, 25, 26, 28, 29, 30,
32, 34, 38, 39, 40, 41, 42, 43, 46(LAA), 48, 71, 106 (Anterix)
|
| |
Carrier Aggregation: 5CA DL / 2CA UL |
| |
Channel Bandwidth: 1.4/3/5/10/15/20 MHz |
| |
Modulation: 256QAM DL / 64QAM UL |
| 5G Antenna |
Low Band: 2×2 MIMO |
| |
Mid Band / High Band: 4×4 MIMO |
| |
2T4R Antenna Chain |
| GNSS |
Embedded multi-GNSS engine for GPS or GLONASS system |
| Transmitting Power |
5G NR bands: Class 3 (23 dBm ±2 dB) |
| |
5G NR HPUE bands: n38/n40/n41/n77/n78/n79 Class 2 (26 dBm ±2 dB) |
| |
LTE bands: Class 3 (23 dBm ±2 dB) |
| |
LTE HPUE bands: B38/B41/B42/B43 Class 2 (26 dBm ±2 dB) |
| Data Transmission |
5G NSA: DL 3.2Gbps / UL 600Mbps |
| |
5G SA: DL 2.4Gbps / UL 900Mbps |
| |
4G/LTE: DL 1.6Gbps / UL 200Mbps |
| |
Presented data rates are theoretical only |
| Network Protocols |
IPv4, IPv6, IPv4 / IPv6 dual stack |
| |
IPv6 in IPv4 (6RD) |
| |
IPv4 in IPv6 (DS-Lite) |
| |
NAT, static routing and RIP-1/2 |
| |
UPnP |
| |
DDNS |
| |
Virtual server and DMZ |
| |
SNTP, DNS relay, IGMP proxy, IGMP snooping |
| |
MLD proxy and MLD snooping |
| |
Port-based VLAN |
| |
Telnet Server, SSH Server, UDP Server/Client, TCP Server/Client direct to Serial interface |
| Utility Protocols |
PTP Ethernet |
| |
Modbus/TCP |
| |
DNP3/TCP |
| |
IEC 61850-90-5 R-GOOSE |
| |
IEC 61850-3 |
| |
IEEE 1613 |
| |
IEEE 2030.5 |
| Firewall |
Built-in NAT Firewall |
| |
Stateful Packet Inspection (SPI) |
| |
DoS attack protection including Land Attack and Ping of Death |
| |
Access Control |
| |
IP Filtering, MAC Filtering, URL Filtering |
| |
Password protection for system management |
| |
VPN Passthrough |
| Management |
Quick Installation Wizard |
| |
Web-based GUI for remote and local management |
| |
Firmware upgrade and configuration upload/download via web GUI |
| |
DHCP server/client/relay |
| |
TR-069 remote management |
| |
SNMP |
| |
Syslog monitoring |
| |
Out-of-Band Management via serial console |
| |
BECentral® Cloud-Based Remote Management |
| VPN |
IPSec VPN Tunneling: up to 8 tunnels |
| |
PPTP VPN Tunneling: up to 4 dial-in/dial-out tunnels |
| |
L2TP over IPSec: up to 4 dial-in/dial-out tunnels |
| |
GRE: up to 8 tunnels |
| |
Embedded PPTP / L2TP / IPSec Client and Server |
| |
IKE Key Management |
| |
MPPE Encryption for PPTP |
| |
IPsec DES, 3DES, and AES encryption |
| |
OpenVPN: 1 server for up to 4 clients |
| Dynamic Routing |
BGP and OSPF |
| Serial Port |
RS-232/RS-485 |
| |
Modbus RTU/ASCII |
| |
DNP3 over Serial |
| Alarm |
Digital Input |
| Physical Interface |
5G WAN: Four (4) SMA Female Connectors |
| |
Ethernet: 2-port 10/100/1000Mbps auto-crossover (MDI/MDI-X) switch |
| |
SIM Card: Two (2) slots, 2FF SIM size |
| |
Serial: DB9 – DTE, two (2) ports |
| |
Alarm: Terminal Block (1) |
| |
Reset Button |
| |
Power Connector: 1×2 Terminal block |
| |
LED Indicators: Power, Internet, LTE Signal Strength, Ethernet 1-2 |
| Power Specifications |
Input: DC 10V~56V |
| Dimensions |
4.9″ (W) x 3.8″ (H) x 1.6″ (D) |
| |
125mm x 98mm x 43mm |
| Operating Environment |
Operating temperature: -40° to 70°C (-40° to 158°F) |
| |
Humidity: 20~95% non-condensing |
| Regulatory Compliance |
FCC Part 15 |
| |
FCC Part 96 |
