If you are a driver, you know how hard it can be to stay safe on the road. One of the biggest problems is not being able to see other cars or objects around you. This can lead to accidents and injuries. The Bosch CAS-M 3 EVO, Collision Avoidance System is a solution to this problem. It helps you see what is around you and warns you if there is a risk of a crash. This product is important because it can save your life. It gives you a clear view of what is happening around your vehicle, so you can make safe decisions while driving.
Bosch CAS-M 3 EVO, Collision Avoidance System with Bosch
Imagine being able to drive with confidence, knowing that you have a system that is watching out for you. The Bosch CAS-M 3 EVO, Collision Avoidance System is a game-changer for drivers. It is a collision avoidance system that uses radar and camera technology to detect objects around your vehicle. This product is used to improve safety on the road. Many drivers have a problem with not being able to see other cars or objects, and this product solves that problem. With the Bosch CAS-M 3 EVO, you can drive safely, knowing that you have a system that is warning you of potential dangers.
Key Features
- Uses radar and camera technology to detect objects
- Provides warnings of potential dangers
- Improves visibility, especially in low-light conditions
- Easy to use and install
- Perfect for professional drivers or anyone who wants to stay safe on the road
- Real-time visualization and driver warning through intuitive marking of vehicles on display
- Full Bosch Motorsport tool integration
- Configuration Tool: RaceCon
- High-performance Bosch Motorsport Display Unit and Rear Module
- Bosch mid-range radar sensor and high-definition camera
Specifications
| General |
|
| Product |
Bosch CAS-M 3 EVO |
| Description |
Collision Avoidance System |
| Order Number |
F02U.V02.648-03 |
| Function |
Real time visualization and driver warning through intuitive marking of vehicles on display |
| System Features |
|
| Approaching Vehicle Tracking |
Supported |
| Left/Right Passing Alerts |
Supported |
| Visibility Improvement |
Improves visibility of objects in rain, mist or darkness |
| System Integration |
Full Bosch Motorsport tool integration |
| Configuration Tool |
RaceCon |
| Radar & Camera System |
|
| System Components |
High-performance Bosch Motorsport Display Unit and Rear Module |
| Rear Module Components |
Bosch mid-range radar sensor and high-definition camera |
| Radar Tracking Objects |
Maximum 40 objects |
| Displayed Classified Objects |
Maximum 4 objects |
| Radar Range |
95 m |
| Camera Range |
95 m |
| Camera Field of View |
78° |
| Radar Field of View |
|
| Horizontal Field of View |
85° from 0 to 29 m |
| Horizontal Field of View |
70° from 29 to 46 m |
| Horizontal Field of View |
50° from 46 to 73 m |
| Horizontal Field of View |
42° from 73 to 78 m |
| Horizontal Field of View |
20° from 78 to 95 m |
| Display Unit |
|
| Display Format |
7” |
| Display Resolution |
800 x 480 pixel |
| Display Size |
198 x 134 x 35 mm |
| Display Weight |
830 g |
| Protection Classification |
IP67 |
| Operating Temperature Internal |
-20 to 85°C |
| Maximum Vibration |
Vibration profile 1 |
| Rear Module |
|
| Rear Module Size |
120 x 150 x 115 mm |
| Rear Module Weight |
880 g |
| Protection Classification |
IP67 |
| Operating Temperature |
0 to 70°C (rearview camera internal temperature) |
| Maximum Vibration |
Vibration profile 1 |
| Electrical Data |
|
| Supply Voltage (Display and Rear Unit) |
6 to 18 V |
| Display Unit Current Consumption |
2 A (at 12 V) |
| Rear Module Current Consumption |
0.7 A (at 12 V) |
| Communication Interfaces |
|
| Display Unit CAN |
1 × private CAN for radar, 1 × CAN |
| Display Unit Ethernet |
1 × private 1GBase-T Ethernet for camera, 1 × 100Base-T Ethernet |
| Time Synchronization Ethernet |
1 |
| Rear Module CAN |
1 × private CAN for radar |
| Rear Module Ethernet |
1 × private 1GBase-T Ethernet for camera |
| Connectors |
|
| Display Unit Connector |
Motorsport connector on device AS212-35PN |
| Rear Module Connector |
Motorsport connector on device AS212-35PN |
| Mating Connector |
AS612-35SN |
| Mating Connector Order Number |
F02U.000.443-01 |
| Software Tools |
|
| Data Analysis Tool |
WinDarab 7 Light |
| System Configuration Tool |
RaceCon |
| Installation Requirements |
|
| Rear Unit Mounting Position |
90° to vehicle vertical and horizontal axis |
| Maximum Lateral Offset |
±200 mm of vehicle lateral centerline |
| Radar Mounting Distance Over Ground |
300 to 1,000 mm |
| Radar View Requirement |
Clear and unobstructed view required |
| Ordering Information |
|
| Collision Avoidance System CAS-M 3 EVO |
F02U.V02.648-03 |
