If you are having trouble with your vehicle's Anti-lock Braking System (ABS), it may be due to a problem with the wheel speed signal. The ABS system relies on accurate wheel speed information to function properly. However, the signal from the wheel speed sensor may not be compatible with the ABS system, leading to errors and malfunctions. The Bosch F02U.V00.335-03, Double Connector Type, Wheel Speed Signal Splitter is designed to solve this problem by converting the wheel speed signal into a format that can be read by the ABS system. This ensures that the ABS system receives accurate information, allowing it to function correctly and improve vehicle safety.
Bosch F02U.V00.335-03, Double Connector Type, Wheel Speed Signal Splitter with Bosch
Are you tired of dealing with ABS system errors and warnings? The Bosch F02U.V00.335-03, Double Connector Type, Wheel Speed Signal Splitter is here to help. This innovative device is designed to work seamlessly with Bosch systems, providing a reliable and accurate wheel speed signal. With its double connector type, it can connect to multiple systems, making it a versatile solution for a variety of applications. Whether you are a professional mechanic or a car enthusiast, this splitter is the perfect tool to ensure your ABS system is functioning properly.
Key Features
- Double connector type for multiple system connections
- Compatible with Bosch DF11 wheel speed sensor interface
- Converts wheel speed signal to a format readable by ABS systems
- Lightweight aluminum housing for durability
- Operating temperature range of -20 to 85C
- Storage temperature range of -20 to 85C
- Max vibration of Vibration Profile 1
- 12V power supply
- Open collector signal output
- ECU ground connection
Specifications
| General |
|
| Product |
Bosch Wheel Speed Signal Splitter |
| Order Number |
F02U.V00.203-03 |
| Connector Type |
Double Connector Type |
| Application |
ABS wheel speed sensor interface |
| Compatible Sensor Type |
Bosch DF11 wheel speed sensor interface |
| Function |
Converts Bosch DF11 (differential dual hall sensors) signals to a signal that can be processed by
peripheral engine controlling devices and data recording systems
|
| Features |
|
| Signal Processing |
Forwards sensor information to ABS and converts speed information into a digital signal |
| Output Type |
Open collector |
| Compatible System |
Bosch Motorsport ABS system |
| Housing |
Lightweight Aluminum Housing |
| Mechanical Data |
|
| Weight |
53 g |
| Size (Double Connector Type) |
112.1 x 63.5 x 30.3 mm |
| Operating Temperature Range |
-20 to 85°C |
| Storage Temperature Range |
-20 to 85°C |
| Max. Vibration |
Vibration Profile 1 |
| Electrical Data |
|
| Power Supply |
12 V |
| Max. Power Supply (1 min) |
25 V |
| Connectors |
|
| Connector Type |
Double Connector |
| Connector 1 |
Wide connector |
| Connector 2 |
Small connector |
| Pinout Connector 1 (Wide) |
|
| Pin 9 |
Signal to ABS (FL) |
| Pin 10 |
DF11 supply from ABS (FL) |
| Pin 11 |
Signal to ABS (FR) |
| Pin 12 |
DF11 supply from ABS (FR) |
| Pin 13 |
Signal to ABS (RL) |
| Pin 14 |
DF11 supply from ABS (RL) |
| Pin 15 |
Signal to ABS (RR) |
| Pin 16 |
DF11 supply from ABS (RR) |
| Pin 17 |
Open collector Signal to ECU (FL) |
| Pin 18 |
Open collector Signal to ECU (FR) |
| Pin 19 |
UBat 12V |
| Pin 20 |
Open collector Signal to ECU (RL) |
| Pin 21 |
Open collector Signal to ECU (RR) |
| Pin 22 |
ECU Ground |
| Pinout Connector 2 (Small) |
|
| Pin 1 |
Open collector Signal to ECU (FL) |
| Pin 2 |
Open collector Signal to ECU (FR) |
| Pin 3 |
Open collector Signal to ECU (RL) |
| Pin 4 |
Open collector Signal to ECU (RR) |
| Pin 5 |
Not used |
| Pin 6 |
ECU Ground |
| Ordering Information |
|
| Order Number |
F02U.V00.203-03 |
