| Management features |
| MIB support |
Y |
| Configuring Location Settings (CLI) |
Yes |
| Web-based management |
Yes |
| Quality of Service (QoS) support |
Yes |
| Switch layer |
L2/L3 |
| Switch type |
Managed |
| Ports & interfaces |
| SFP+ module slots quantity |
2 |
| 2.5G Ethernet (copper) ports quantity |
4 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity |
4 |
| Network |
| Virtual LAN features |
Private VLAN, Voice VLAN |
| VLAN support |
Yes |
| Auto MDI/MDI-X |
Yes |
| Broadcast storm control |
Yes |
| Head-of-line (HOL) blocking |
Yes |
| Link aggregation |
Yes |
| Rate limiting |
Yes |
| Spanning tree protocol |
Yes |
| Policy-based routing |
Yes |
| Port mirroring |
Yes |
| Networking standards |
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3an, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Data transmission |
| Packet buffer memory |
1.5 MB |
| Jumbo frames |
9000 |
| Jumbo frames support |
Yes |
| Static route |
Yes |
| Number of queues |
8 |
| Switching capacity |
56 Gbit/s |
| MAC address table |
16000 entries |
| Security |
| Authentication |
MAC-based authentication, Web-based authentication |
| Authentication type |
RADIUS, TACACS+ |
| Queue scheduling algorithms |
Weighted Round Robin (WRR) |
| SSH/SSL support |
Yes |
| Security algorithms |
HTTPS, SNMP, SNMPv2, SNMPv3, SSH, SSH-2 |
| IGMP proxy |
Yes |
| IGMP snooping |
Yes |
| Access Control List (ACL) rules |
1024 |
| Access Control List (ACL) |
Yes |
| DHCP features |
DHCP auto-config, DHCP client, DHCP relay, DHCP server, DHCP snooping |
| Multicast features |
| Multicast support |
Yes |
| Protocols |
| IPv4 & IPv6 features |
ICMPv6, IPv6 SNMP, IPv6 SSH, IPv6 TFTP, IPv6 Telnet |
| GARP VLAN Registration Protocol (GVRP) |
Yes |
| Design |
| LED indicators |
Yes |
| Reset button |
Yes |
| Product colour |
Grey |
| Rack mounting |
Yes |
| Performance |
| Built-in processor |
Yes |
| Power |
| Power plug type |
Type C |
| AC input frequency |
50/60 Hz |
| AC input voltage |
100 - 220 V |
| Power source |
AC |
| Power over Ethernet (PoE) |
| Power over Ethernet (PoE) |
Yes |
| Operational conditions |
| Operating temperature (T-T) |
-5 - 50 °C |
| Storage relative humidity (H-H) |
10 - 90% |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage temperature (T-T) |
-25 - 70 °C |
| Operating temperature (T-T) |
-5 - 50 °C |
| Weight & dimensions |
| Weight |
2.64 kg |
| Height |
44 mm |
| Depth |
323 mm |
| Width |
268 mm |
| Packaging data |
| Package weight |
3.75 kg |
| Package height |
108 mm |
| Package depth |
398.8 mm |
| Package width |
441.3 mm |
