Cisco UCSC-RAID-HP Tri-Mode 24Gb/s SAS RAID Controller

Cisco UCSC-RAID-HP Tri-Mode 24Gb/s SAS RAID Controller

The Cisco UCSC-RAID-HP is a Tri-Mode SAS RAID Controller designed for compatible Cisco UCS server configurations. It supports SAS, SATA, and NVMe drive interfaces, providing flexible storage connectivity for enterprise server environments.

The controller supports SAS interface speeds up to 24Gb/s and supports drive speeds of 3Gbps, 6Gbps, 12Gbps, and 24Gbps. It features 4GB of Flash-Backed Write Cache (FBWC) for cache-supported storage operations.

The UCSC-RAID-HP supports RAID 0, 1, 5, 6, 10, 50, and 60, along with JBOD and mixed RAID/JBOD modes. It can support up to 16 drives depending on the supported UCS server configuration.

NVMe RAID is supported on applicable UCS configurations, while Self-Encrypting Drive support and local key management provide additional storage security capabilities. A SuperCap is supported or included depending on the server configuration.

The controller uses a dedicated internal controller slot and is managed through Cisco CIMC / UCSM. The controller vendor is listed as LSI, and Cisco lists firmware version 8.10.1.0-00065-00002 for this controller.

Key Features

• Cisco UCSC-RAID-HP Tri-Mode SAS RAID Controller

• 24Gb/s SAS interface speed

• Supports SAS, SATA, and NVMe drives

• 4GB Flash-Backed Write Cache

• Supports RAID 0, 1, 5, 6, 10, 50, and 60

• Supports JBOD and mixed RAID/JBOD mode

• Up to 16 drives depending on UCS server configuration

• NVMe RAID support on applicable UCS configurations

• Self-Encrypting Drive support with local key management

• Cisco CIMC / UCSM management

• Dedicated internal controller slot

• LSI controller vendor

Specifications
