Corning EDGE8-01U-FP EDGE8 1U Fiber Optic Housing, Fixed Tray, 12 Modules

Imagine a data center where every fiber connection snaps into place without a fuss, and you never have to worry about cramped racks or loose panels. The Corning EDGE8-01U-FP EDGE8 1U Fiber Optic Housing, Fixed Tray, 12 Modules is exactly that solution. It is a compact 1-U rack unit that holds twelve EDGE8 modules, giving you 96 fiber ports in a tidy, silver-finished frame. If you have been fighting with oversized housings, mismatched adapters, or unreliable cable management, this product removes those headaches and lets you focus on keeping your network fast and reliable.

Corning EDGE8-01U-FP EDGE8 1U Fiber Optic Housing, Fixed Tray, 12 Modules

Data centers need dense, organized fiber routing to avoid downtime. When space is limited, a bulky housing can block airflow and make maintenance a nightmare. This fixed-tray housing solves the problem by delivering high density in a single-U footprint, keeping your rack tidy and your cooling efficient. It meets RoHS standards, so you get a safe, environmentally friendly product that fits any modern data-center design.

Benefits

• Maximum fiber density: 96 ports in one 1-U unit, freeing up rack space for other equipment.
• Easy installation: Fixed tray design and included mounting kit let you set up quickly without special tools.
• Stable performance: Silver housing and robust construction protect fibers from vibration and temperature changes.
• Future-proof: Supports both size 1 and size 2 trunks, so you can expand as your network grows.
• Compliance ready: RoHS-free materials meet strict environmental regulations.

Usages

The EDGE8-01U-FP is ideal for high-performance data centers that need to pack many fiber connections into limited rack space. Use it in core aggregation layers, where dozens of 40 Gbps or 100 Gbps links converge. It also works well in edge routers and switches that require clean, organized fiber trays. Small to medium enterprises can install it in server rooms to upgrade from copper to fiber without overhauling the whole rack layout.

Key Features

• 12 fixed EDGE8 modules per housing
• 96 fiber capacity (12 modules × 8 fibers each)
• Height: 1 U (44 mm) for ultra-compact installation
• Width: 432 mm, Depth: 437 mm - fits standard 19-inch racks
• Silver color housing for easy visual identification
• RoHS 2011/65/EU compliant, free of hazardous substances
• Supports trunk sizes 1 or 2, up to 8 trunks per unit
• Shipping weight 4.4 kg, easy to handle during deployment
• Package contains fixed 1U housing, mounting kit, and accessories for a complete setup
