The DES-1024D 24-Port Fast Ethernet Unmanaged Desktop Switch is designed to enhance workgroup performance while providing a high level of flexibility. Powerful yet easy to use, this device allows users to simply plug any port to either a 10Mbps or 100Mbps network to multiply bandwidths, boost response time and satisfy heavy load demands.
With the D-Link 24-Port Fast Ethernet Unmanaged Switches, you can easily expand your business or home network by adding more computers and devices, each achieving speeds up to 200 Mbps per port in full-duplex mode. Quickly and securely connect employees working in small offices with one another and with all of the servers, printers, and other devices they use. High performance and reliable connectivity help speed file transfers and data processing, improve network uptime, and keep your employees connected and productive.
Expand and Upgrade Your Network
The DES-1024D switch offers an economical way for SOHO and small to medium businesses (SMB) to benefit from high-speed networking. It provides twenty-four ports for easy expansion of your network and a quick way to upgrade your network to Fast Ethernet connectivity. The switches speed file transfer times, improve slow and sluggish networks, keep your vital business applications available, and help your employees respond more quickly to customers and each other.
Conserve Energy
The DES-1024D switch helps you conserve energy through IEEE802.3az EEE, which works when both the switch and its link partner are EEE-compliant devices. This power-saving feature automatically puts the switch into a low-power idle state when the switch utilization is zero, allowing you to lower your energy usage and save on your energy costs.
Designed with the Environment in Mind
The DES-1024D switch uses recyclable packaging that helps reduce waste, complying with the WEEE directive. It’s innovatively designed to run cool and quiet without sacrificing performance.
Specifications
| Management features |
| Quality of Service (QoS) support |
Yes |
| Switch type |
Unmanaged |
| Ports & interfaces |
| Installed SFP+ modules quantity |
0 |
| Installed SFP modules quantity |
0 |
| Basic switching RJ-45 Ethernet ports type |
Fast Ethernet (10/100) |
| Basic switching RJ-45 Ethernet ports quantity |
24 |
| Network |
| Auto MDI/MDI-X |
Yes |
| Auto-negotiation |
Yes |
| Auto-sensing |
Yes |
| Ethernet LAN data rates |
10,100 Mbit/s |
| Flow control support |
Yes |
| MAC address auto-learning supported |
Yes |
| Full duplex |
Yes |
| Half duplex |
Yes |
| Copper ethernet cabling technology |
10BASE-T, 100BASE-TX |
| 10G support |
No |
| Networking standards |
IEEE 802.1D, IEEE 802.3, IEEE 802.3U, IEEE 802.3x |
| Data transmission |
| Packet forwarding rate (10 Mbps) |
14.88 pps |
| Packet forwarding rate (100 Mbps) |
148.8 pps |
| Store-and-forward |
Yes |
| Switching capacity |
4.8 Gbit/s |
| Supported data transfer rates |
100 Mbps |
| MAC address table |
8000 entries |
| Protocols |
| Supported network protocols |
CSMA/CD |
| Data link protocols |
Ethernet, Fast Ethernet |
| Switching protocols |
Ethernet |
| Design |
| LED indicators |
Activity, Link, Power |
| Product colour |
Black |
| Stackable |
No |
| Performance |
| Mean time between failures (MTBF) |
810.88 h |
| Internal memory |
2 MB |
| Power |
| Power consumption (max) |
2.8 W |
| AC input frequency |
50/60 Hz |
| AC input voltage |
100 - 240 V |
| Power supply included |
Yes |
| Power source |
AC |
| Power over Ethernet (PoE) |
| Power over Ethernet (PoE) |
No |
| Other features |
| I/O ports |
24-10/100Mbps RJ-45 Auto-sensing ports |
| Networking features |
10/100Base – EIA/TIA Categories 3 or 5 cable |
| Connectivity technology |
Wired |
| Dimensions (WxDxH) |
280 x 180 x 44 mm |
| Operational conditions |
| Heat dissipation |
9.5536 BTU/h |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage relative humidity (H-H) |
5 - 90% |
| Operating relative humidity (H-H) |
5 - 90% |
| Storage temperature (T-T) |
-10 - 70 °C |
| Operating temperature (T-T) |
0 - 40 °C |
| Weight & dimensions |
| Weight |
1.14 kg |
| Height |
44 mm |
| Depth |
150 mm |
| Width |
280 mm |
| Packaging data |
| Package weight |
1.9 kg |
| Package height |
78 mm |
| Package depth |
376 mm |
| Package width |
282 mm |
| Certificates |
| Compliance certificates |
BSMI, CB, CCC, CE, Federal Communications Commission (FCC), ICES, Low Voltage Directive (LVD), RCM, VCCI, cUL |
| Technical details |
| Master (outer) cases per pallet (air) |
24 pc(s) |
| Master (outer) cases per pallet (sea) |
36 pc(s) |
| Pallet gross length |
120 cm |
| Pallet gross weight (air) |
265.9 kg |
| Pallet gross weight (sea) |
390.3 kg |
| Pallet gross width |
110 cm |
| Pallet height (air) |
137.9 cm |
| Pallet height (sea) |
2 m |
| Products per pallet (air) |
120 pc(s) |
| Products per pallet (sea) |
180 pc(s) |
| Products per shipping (inner) case |
5 pc(s) |
| Shipping (inner) case gross weight |
10.4 kg |
| Shipping (inner) case height |
31.1 cm |
| Shipping (inner) case length |
42 cm |
| Shipping (inner) case net weight |
9.5 kg |
| Shipping (inner) case width |
39.2 cm |
