The DGS-1008D 8-Port Gigabit Desktop Switch is part of D-Link’s series of SOHO devices that allows you to easily expand and upgrade your network. D-Link’s Green Technology provides energy savings, reduces heat, and a longer product life without sacrificing performance or functionality. DGS-1008D provides eight Gigabit ports for easy expansion of your network and a quick way to upgrade your network to Gigabit connectivity. An energy-efficient power adapter (Energy Star Level V qualified), minimised use of harmful substances (RoHS compliant), and recyclable packaging make this switch truly environmentally friendly.
Fast and Reliable Networking
The D-Link DGS-1008D 8-Port Gigabit Desktop Switch creates a blazing fast network for your office, as its Gigabit Ethernet ports provide high-speed wired connections for up to eight PCs or other devices. The DGS-1008D also features QoS, which prioritises network traffic so that time-sensitive data is delivered efficiently, even during bursts of high data traffic. It’s stylish, easy-to-use, and comes IPv6-ready for a reliable network today and tomorrow.
Conserve Energy
The 8-Port Gigabit Desktop Switch helps you conserve energy automatically through several methods. It automatically powers down ports that have no link, allowing the switch to save a substantial amount of power by cutting power usage for unused ports. It also adjusts the amount of power supplied to a port according to the length of the connected Ethernet cable.
Environmentally-friendly
The 8-Port Gigabit Desktop Switch was designed with the environment in mind, and is compliant with Energy Star Level V, as well as with the stringent CEC and MEPS regulations that require the use of energy efficient power adapters. The switch is also built to follow RoHS standards to minimise the use of hazardous materials, and uses recyclable packaging that helps reduce waste, complying with the WEEE directive.
Specifications
| Management features |
| Switch layer |
L2 |
| Switch type |
Unmanaged |
| Ports & interfaces |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity |
8 |
| Network |
| Full duplex |
Yes |
| Data transmission |
| Jumbo frames support |
Yes |
| Maximum data transfer rate |
1 Gbit/s |
| Switching capacity |
16 Gbit/s |
| MAC address table |
8000 entries |
| Design |
| Safety |
CSA |
| Rack mounting |
No |
| Performance |
| Maximum data transfer rate |
1 Gbit/s |
| Power |
| Power consumption (typical) |
4.5 W |
| Power over Ethernet (PoE) |
| Power over Ethernet (PoE) |
No |
| Other features |
| Electromagnetic emissions |
CE Mark, FCC Class B |
| I/O ports |
8 x 10/100/1000BASE-T |
| Networking features |
10BASE-T, 100BASE-TX & 1000BASE- T |
| Power LED |
No |
| Power requirements |
7.5V 1A |
| Connectivity technology |
Wired |
| Dimensions (WxDxH) |
192 x 118 x 30 mm |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage temperature (T-T) |
-10 - 70 °C |
| Operating temperature (T-T) |
0 - 40 °C |
| Weight & dimensions |
| Weight |
300 g |
| Packaging data |
| Package weight |
280 g |
| Package height |
94 mm |
| Package depth |
158 mm |
| Package width |
104 mm |
| Technical details |
| Master (outer) cases per pallet (air) |
100 pc(s) |
| Master (outer) cases per pallet (sea) |
100 pc(s) |
| Pallet gross length |
110 cm |
| Pallet gross weight (air) |
350.2 kg |
| Pallet gross weight (sea) |
350.2 kg |
| Pallet gross width |
120 cm |
| Pallet height (air) |
2.06 m |
| Pallet height (sea) |
2.06 m |
| Products per pallet (air) |
1000 pc(s) |
| Products per pallet (sea) |
1000 pc(s) |
| Products per shipping (inner) case |
10 pc(s) |
| Shipping (inner) case gross weight |
3.32 kg |
| Shipping (inner) case height |
19.3 cm |
| Shipping (inner) case length |
49.8 cm |
| Shipping (inner) case net weight |
1.9 kg |
| Shipping (inner) case width |
23 cm |
