When your office network needs to stretch beyond the limits of copper cabling, you often face costly rewiring or unreliable signal loss. The 1000Base-T to 1000Base-LX Media Converter solves that problem by turning a standard Ethernet link into a long-reach fiber connection, letting you extend gigabit speeds up to 10 km without replacing existing equipment. It is a compact, plug-and-play device that bridges copper and single-mode fiber, making high-speed networking simple and affordable.
Extend Your Network with the 1000Base-T to 1000Base-LX Media Converter
Many businesses struggle with distance-related network bottlenecks, especially when connecting remote offices or outdoor sites. A weak link can slow down data transfer, cause dropped packets, and hurt productivity. This media converter removes those obstacles by converting 1000Base-T copper signals to 1000Base-LX fiber, delivering reliable gigabit performance over long distances. The solution is ideal for expanding LANs, linking data centers, or connecting surveillance cameras that require stable, high-bandwidth links.
Usages
The converter fits into any environment where copper cannot reach or where interference is a concern. It works well in:
- Office extensions across campus buildings
- Outdoor fiber runs to remote sites
- Surveillance systems needing long-haul video streams
- Industrial settings with high electromagnetic noise
Benefits
You get a seamless upgrade path without overhauling your whole network. The device’s auto-MDI support means you never need crossover cables, saving time and reducing errors. Its low power consumption (1.5 W max, 1.3 W standby) keeps energy costs down while still delivering robust performance. With a 1 Mbit packet buffer and store-and-forward mode, the converter handles burst traffic smoothly, preventing data loss. Certified for CE and FCC, it meets global safety and EMI standards, giving you confidence in its reliability.
Key Features
- Converts 1000Base-T to 1000Base-LX for long-distance fiber links
- Operates on 1300 nm single-mode fiber wavelength
- Supports up to 10 km maximum distance
- One RJ-45 port and two SC-type fiber ports for flexible connections
- Single-mode operation for high-precision signal transmission
- Standalone use only, no external devices required
- Auto MDI support eliminates the need for special cables
- Operating temperature range 0 °C to 50 °C for diverse environments
- Power options: AC 240 V or DC +5 V with external adapter included
- Store-and-forward forwarding mode with 1 Mbit packet buffer memory
This media converter gives you the freedom to expand your network quickly, securely, and cost-effectively, turning distance from a limitation into an advantage.
Specifications
| Description |
Converts 1000 Base - T to 1000 Base - LX |
| Fiber wavelength |
1300 nm |
| Max distance |
10 Km |
| Ports |
One RJ - 45 and two Fiber port (SC type connector) |
| Mode |
Single - mode |
| Used with |
Standalone only |
| Auto MDI support |
Yes |
| Operating Temperature |
0° C to 50° C |
| Storage Temperature |
-20° C to 70° C |
| Operating Humidity |
5% to 90% non - condensing |
| Operating Voltage |
AC 240V or DC +5V |
| Forwarding mode |
Store and Forward |
| Packet Buffer Memory |
1Mbit |
| External Power Adapter |
Yes |
| Power Consumption Max at 240 V |
1.5W |
| Power Consumption Standby at 240 V |
1.3W |
| MTBF - hours |
10,0000 hours |
| Emission EMI and Safety Certifications |
CE, FCC |
| Dimensions |
94 × 70 × 26 mm |
