2.5G Speed, Ready for Wi-Fi 6 and More
The DMS-1250 Series switches can enhance your network by connecting a Wi-Fi 6 Access Point to any of the 2.5 Gbps ports, effectively maximizing throughput and speed. Multi-Gigabit Ethernet eliminates potential bottlenecks with Wi-Fi 6 Access Points, enabling your network to fully leverage the efficiency and high speeds offered by Wi-Fi 6.
Cutting-Edge PoE Features Ensuring
Reliable Power Delivery
PoE+ ports provide a high power budget to fulfill the most business needs.
The innovative PoE functions can ensure uninterrupted power delivery to the power devices.
Intelligent Fan Control with Quiet Operation
The DMS-1250 PoE models with built-in internal fans which can automatically work between 5 levels of cooling to prevent the device from overheating or manually set to OFF or Quiet mode according to environment or operation temperature.
6 kV Surge Protection for All Ethernet Ports
The DMS-1250 Series switches offer enhanced 6kV surge protection on all 2.5-Gigabit Ethernet access ports, ensuring that your network remains resilient and that your devices stay safe from electrical surges.
Easy Management by DNC & D-View 8
The DMS-1250 Series switches offers a range of management tools to cater to users' diverse needs. D-Link Nuclias Controller (DNC) and D-Link Nuclias Hub (DNH) enable the discovery and management of multiple D-Link devices, providing access to configure settings efficiently. Furthermore, the DMS-1250 Series can be seamlessly managed through D-View 8, a comprehensive central network management system. SNMP functionality allows for centralized network asset management, remote configuration, and logging functions.
Best Choice for SOHO, SMB and MDU
The DMS-1250 Series switches are versatile, suitable for SOHO, SMB, and MDU environments. They provide high-speed data transmission with 2.5GE and a crucial 10G speed uplink for external connectivity. This high-speed uplink ensures that the entire MDU can access external services without encountering data bottlenecks. Furthermore, they effectively implement IEEE 802.3at or IEEE 802.3bt in DMS-1250-10SP, 10SPL, and 12TP to enable devices to connect and receive power supply.
Specifications
| Management features |
| MIB support |
Y |
| ARP inspection |
Yes |
| Web-based management |
Yes |
| Quality of Service (QoS) support |
Yes |
| Switch type |
Managed |
| Ports & interfaces |
| Power connector |
AC-in jack |
| Combo SFP ports quantity |
2 |
| 10G Ethernet (copper) ports quantity |
2 |
| 2.5G Ethernet (copper) ports quantity |
8 |
| Basic switching RJ-45 Ethernet ports type |
2.5G Ethernet (100/1000/2500) |
| Basic switching RJ-45 Ethernet ports quantity |
10 |
| Network |
| Number of VLANs |
4094 |
| VLAN support |
Yes |
| Broadcast storm control |
Yes |
| Ethernet LAN data rates |
1000,100,2500 Mbit/s |
| Flow control support |
Yes |
| Spanning tree protocol |
Yes |
| Port mirroring |
Yes |
| 10G support |
Yes |
| Networking standards |
IEEE 802.3ab, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3an, IEEE 802.3u, IEEE 802.3at, IEEE 802.3z, IEEE 802.3az |
| Data transmission |
| Jumbo frames |
12000 |
| Jumbo frames support |
Yes |
| Number of static routes |
128 |
| Static route |
Yes |
| Store-and-forward |
Yes |
| Forwarding rate |
89.29 Mpps |
| Switching capacity |
120 Gbit/s |
| MAC address table |
16000 entries |
| Security |
| Authentication type |
RADIUS |
| Loop protection |
Yes |
| Password protection |
Yes |
| IGMP entries |
256 |
| IGMP snooping |
Yes |
| Access Control List (ACL) IPv6 entries |
384 |
| Access Control List (ACL) IPv4 entries |
768 |
| Access Control List (ACL) |
Yes |
| DHCP features |
DHCP server, DHCP client, DHCP snooping |
| Design |
| LED indicators |
Yes |
| Reset button |
Yes |
| Product colour |
Black |
| Rack mounting |
Yes |
| Performance |
| Flash memory |
32 MB |
| Internal memory |
512 MB |
| Memory type |
DRAM |
| Power |
| Power consumption (max) |
289.74 W |
| AC input frequency |
50/60 Hz |
| AC input voltage |
100 - 240 V |
| Power supply included |
Yes |
| Power source |
AC |
| Power over Ethernet (PoE) |
| Total Power over Ethernet (PoE) budget |
240 W |
| Power over Ethernet (PoE) power per port |
30 W |
| Power over Ethernet (PoE) ports quantity |
8 |
| Power over Ethernet (PoE) |
Yes |
| Operational conditions |
| Operating temperature (T-T) |
-5 - 50 °C |
| Storage relative humidity (H-H) |
0 - 95% |
| Operating relative humidity (H-H) |
0 - 95% |
| Storage temperature (T-T) |
-20 - 70 °C |
| Operating temperature (T-T) |
-5 - 50 °C |
| Weight & dimensions |
| Weight |
3.24 kg |
| Height |
44 mm |
| Depth |
210 mm |
| Width |
440 mm |
| Packaging content |
| Quick start guide |
Yes |
| Certificates |
| Certification |
CB, UL, BSMI, CE Class A, VCCI Class A, FCC Class A, IC, BSMI, RCM |
