Darveen MP-240, Intel Core i5-10210U, 23.8″ Marine Panel PC
The Darveen MP-240 is a 23.8-inch Marine Panel PC designed for marine environments where a large display, reliable computing, and flexible connectivity are needed in a compact panel-mount system. Its multi-touch capacitive TFT-LCD screen provides a clear interface for marine monitoring, control, navigation, and industrial applications.
Powered by an Intel Core i5-10210U processor with 1.6 GHz speed and support for up to 64GB DDR4 memory, the MP-240 provides the computing capacity needed for demanding marine software and operational workloads. Its 1920 x 1080 resolution, 550 nits luminance, 1000:1 contrast ratio, and 16.7 M color support provide detailed and readable visual output.
The panel PC provides four USB 3.0 ports, three COM ports, four GbE LAN ports, and one HDMI interface for connecting peripherals, control equipment, displays, and network devices. Optional Wi-Fi, cellular, Bluetooth, and 4G connectivity provide additional communication flexibility for different marine system configurations.
The MP-240 supports a 2.5-inch SATA HDD/SSD and a full-length Mini PCIe slot for mSATA SSD storage. Its aluminum alloy panel and all-metal chassis, panel-mount and VESA 100 mounting options, and IP65-compliant front panel make it suitable for integrated marine workstations, vessel control systems, monitoring stations, and other space-conscious installations.
With 9 to 36VDC input, 27W power consumption, Windows 10 and Windows 11 support, and an operating temperature range of -10 to 50°C, the Darveen MP-240 is designed for practical deployment in marine and industrial environments. Its display, processing, networking, expansion, and mounting features allow it to serve as a central interface for marine monitoring and control applications.
Key Features
-
23.8-inch multi-touch capacitive TFT-LCD display
-
Intel Core i5-10210U processor at 1.6 GHz
-
2x DDR4 2666 SO-DIMM supporting up to 64GB
-
1920 x 1080 resolution with 550 nits luminance
-
4x USB 3.0, 3x COM, and 4x GbE LAN ports
-
Optional Wi-Fi, cellular, Bluetooth, and 4G connectivity
-
9 to 36VDC input with 27W power consumption
-
IP65-compliant front panel and aluminum alloy panel
Specifications
| Display |
|
| Size |
23.8 inch |
| Touch Type |
Multi touch capacitive screen |
| Display Type |
TFT-LCD |
| Transmitiance |
87% (capacitive) |
| Control Interface |
USB |
| Surface Hardness |
≥7H |
| Resolution |
1920 x 1080 |
| Luminance |
550 nits |
| Contrast Ratio |
1000:1 |
| View Angles |
89 (left), 89 (right), 89 (up), 89 (down) |
| LED Lifetime |
30,000 hrs |
| Color |
16.7 M |
| CPU |
|
| CPU |
Intel® Core™ i5-10210U (1.6 GHz) |
| Memory |
|
| Memory |
2x DDR4 2666 SO-DIMM (up to 64GB) |
| Storage |
|
| Storage |
1x 2.5" SATA HDD/SSD (optional) 1x full length Mini PCIe for mSATA SSD |
| USB |
|
| USB |
4x USB 3.0 |
| Serial |
|
| Serial |
3x COM (COM1 supports RS-232, COM2 and COM3 support RS-232/422/485) |
| Ethernet |
|
| Ethernet |
4x GbE LAN |
| Display |
|
| Display |
1x HDMI |
| Antenna |
|
| Antenna |
1x SIM slot for 4G (optional), 2x SMA antenna holes |
| Expansion Slot |
|
| Expansion Slot |
Mini PCle |
| Expansion |
1x full length Mini PCIe for Wi-Fi; 1x full length Mini PCIe for mSATA |
| RF Communication |
|
| Wi-Fi |
Mini PCIe expansion (optional) |
| Cellular |
Mini PCIe expansion (optional) |
| Bluetooth |
Mini PCle expansion (optional) |
| Audio |
|
| Audio |
Mic in, line out |
| Speaker |
20 5W speaker (optional) |
| Power |
|
| Button |
Yes |
| Remote Power On/Of |
N/A |
| DC Input |
9 to 36VDC |
| Power Connector |
4 Pin |
| Power Consumption |
27 W |
| Ignition On/Off |
1x AC loss |
| Power Adaptor |
AC-DC, [email protected], 84W |
| Operating System |
|
| Windows |
Windows 10, Windows 11 |
| Mechanical |
|
| Dimensions (WxDx (H |
587.6 x 376 x 74.4 mm (23.1 x 14.8 x 2.9 inches) |
| Weight (N.W.) |
8.6 kg (19 lbs) |
| Mounting |
Panel mount, wall mount bracket VESA 100 |
| Material |
Aluminum alloy panel, all-metal chassis |
| Environment |
|
| Operating Temperature |
-10 to 50°C (14 to 122°F) |
| Storage Temperature |
-20 to 60°C (-4 to 140°F) |
| Relative Humidity |
10% to 95% @ 40°C (104°F), non-condensing |
| Vibration |
5 to 500Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis |
| IP Rating |
IP65 compliant (for front panel) |
| Certification |
|
| EMC |
CE, FCC |
| Packing List |
|
| Packing List |
1x MP-240 |
| Packing List |
14x panel mounting buckles |
| Packing List |
1x warranty card |
