Product Code: SCNR-067
MPN #: GD4590-WH
Tired of missed scans and slow checkout lines? The Datalogic Gryphon GD4590-WH 1D/2D 1280 x 800 pixels Handheld Barcode Scanner is a high-performance handheld reader that captures every barcode quickly and accurately. It is built for busy retail floors, warehouses, and healthcare desks where a single missed read can cause delays and frustration. With this scanner you get reliable data capture, so you never lose a sale or waste time fixing errors.
This scanner solves the problem of unreliable barcode reading in bright or dim environments. When lighting changes, many scanners lose focus and produce errors, which means extra work for you. The Gryphon GD4590-WH uses warm-white illumination and a megapixel sensor that sees clearly in sunlight, shadows, or under fluorescent lights. The result is a clear solution that lets you scan 1D and 2D codes without changing settings, keeping your workflow smooth.
Fast and accurate 1D/2D barcode scanning with 1280 x 800 megapixel sensor
Reliable performance in bright sunlight and low-light environments up to 100000 lx
Durable IP52 shock-resistant design for retail, warehouse, and healthcare use
Supports USB, RS-232, and Keyboard Wedge interfaces for flexible connectivity
Wide scanning angles with 360° tilt and high motion tolerance for smooth workflow
| Scanning | |
| Motion tolerance (cm/s) | 88.9 |
| Yaw reading angle | -65 - 65° |
| Pitch reading angle | -65 - 65° |
| Tilt reading angle | 0 - 360° |
| Wavelength | 650 nm |
| Light levels (direct sunlight) | 0 - 100000 lx |
| Optical sensor resolution (W x H) | 1280 x 800 pixels |
| 2D (matrix & stacked) barcodes supported | Aztec Code, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code |
| Linear (1D) barcodes supported |
Code 39, EAN-13, GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, PDF417, Planet, POSTNET, U.P.C. |
| Scanner type | 1D/2D |
| Type | Handheld bar code reader |
| Ports & interfaces | |
| Standard interfaces | RS-232, USB, Keyboard wedge |
| Connectivity technology | Wired |
| Performance | |
| Certification | IEC 60825 Class 2 |
| Image formats supported | BMP, JPEG |
| Built-in display | No |
| Protection features | Shock resistant |
| International Protection (IP) code | IP52 |
| Product colour | White |
| Power | |
| Power consumption | 300 mA |
| Input voltage | 4.5 - 14 V |
| Power source type | DC |
| Weight & dimensions | |
| Weight | 161 g |
| Height | 166 mm |
| Depth | 109 mm |
| Width | 68 mm |
| Operational conditions | |
| Operating relative humidity (H-H) | 0 - 95% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Technical details | |
| Compliance certificates | RoHS |
