| Design |
| Market positioning |
Business |
| Form factor |
Clamshell |
| Product colour |
Black |
| Product type |
Laptop |
| Display |
| LED backlight |
Yes |
| Native aspect ratio |
16:9 |
| HD type |
HD |
| Touchscreen |
No |
| Display resolution |
1366 x 768 pixels |
| Display diagonal |
31.8 cm (12.5") |
| Processor |
| ECC supported by processor |
No |
| Maximum number of PCI Express lanes |
12 |
| PCI Express configurations |
1x2+2x1, 1x4, 2x2, 4x1 |
| PCI Express slots version |
3.0 |
| Tjunction |
100 °C |
| Configurable TDP-down |
7.5 W |
| Configurable TDP-down frequency |
0.8 GHz |
| Configurable TDP-up |
25 W |
| Configurable TDP-up frequency |
2.7 GHz |
| Thermal Design Power (TDP) |
15 W |
| Stepping |
H0 |
| Bus type |
OPI |
| Processor codename |
Kaby Lake |
| Processor operating modes |
64-bit |
| Processor lithography |
14 nm |
| Processor socket |
BGA 1356 |
| Processor cache type |
Smart Cache |
| Processor cache |
3 MB |
| System bus rate |
4 GT/s |
| Processor frequency |
2.5 GHz |
| Processor boost frequency |
3.1 GHz |
| Processor threads |
4 |
| Processor cores |
2 |
| Processor model |
i5-7200U |
| Processor generation |
7th gen Intel® Core™ i5 |
| Processor family |
Intel® Core™ i5 |
| Processor manufacturer |
Intel |
| Memory |
| Maximum internal memory |
16 GB |
| Memory slots |
1x SO-DIMM |
| Memory clock speed |
2400 MHz |
| Memory form factor |
SO-DIMM |
| Internal memory type |
DDR4-SDRAM |
| Internal memory |
8 GB |
| Storage |
| Compatible memory cards |
SD |
| Card reader integrated |
Yes |
| Optical drive type |
No |
| SSD capacity |
128 GB |
| Number of SSDs installed |
1 |
| Storage media |
SSD |
| Total storage capacity |
128 GB |
| Graphics |
| On-board graphics card ID |
0x5916 |
| On-board graphics card OpenGL version |
4.4 |
| On-board graphics card DirectX version |
12.0 |
| Maximum on-board graphics card memory |
32 GB |
| On-board graphics card base frequency |
300 MHz |
| On-board graphics card dynamic frequency (max) |
1000 MHz |
| On-board graphics card model |
Intel® HD Graphics 620 |
| Discrete graphics card model |
Not available |
| Discrete graphics card |
No |
| On-board graphics card |
Yes |
| Audio |
| Built-in microphone |
Yes |
| Speaker power |
2 W |
| Number of built-in speakers |
2 |
| Audio chip |
Realtek ALC3246 |
| Camera |
| Video capturing speed |
30 fps |
| Front camera resolution |
1280 x 720 pixels |
| Front camera |
Yes |
| Network |
| Bluetooth version |
4.1 |
| Bluetooth |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Ethernet LAN |
Yes |
| Wi-Fi standards |
802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Top Wi-Fi standard |
Wi-Fi 5 (802.11ac) |
| Wi-Fi |
Yes |
| Ports & interfaces |
| USB Sleep-and-Charge ports |
1 |
| USB Sleep-and-Charge |
Yes |
| Charging port type |
DC-in jack |
| Docking connector |
No |
| Combo headphone/mic port |
Yes |
| Thunderbolt 3 ports quantity |
0 |
| Thunderbolt ports quantity |
0 |
| VGA (D-Sub) ports quantity |
0 |
| DVI port |
No |
| DisplayPorts quantity |
0 |
| HDMI version |
1.4 |
| HDMI ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| USB 2.0 ports quantity |
0 |
| Performance |
| Motherboard chipset |
Intel SoC |
| Keyboard |
| Windows keys |
Yes |
| Full-size keyboard |
Yes |
| Keyboard backlit |
Yes |
| Numeric keypad |
No |
| Pointing device |
Touchpad |
| Software |
| Drivers included |
Yes |
| Operating system architecture |
64-bit |
| Operating system installed |
Windows 10 Pro |
| Processor special features |
| Conflict-Free processor |
Yes |
| CPU configuration (max) |
1 |
| Embedded options available |
No |
| Enhanced Intel SpeedStep Technology |
Yes |
| Execute Disable Bit |
Yes |
| Graphics & IMC lithography |
14 nm |
| Idle States |
Yes |
| Intel 64 |
Yes |
| Intel Clear Video Technology |
Yes |
| Intel Enhanced Halt State |
Yes |
| Intel Flex Memory Access |
Yes |
| Intel Identity Protection Technology version |
1.00 |
| Intel Secure Key Technology version |
1.00 |
| Intel Smart Response Technology version |
1.00 |
| Intel Software Guard Extensions (Intel SGX) |
Yes |
| Intel Stable Image Platform Program (SIPP) |
No |
| Intel Stable Image Platform Program (SIPP) version |
0.00 |
| Intel TSX-NI |
No |
| Intel TSX-NI version |
0.00 |
| Intel Trusted Execution Technology |
No |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Intel Virtualization Technology (VT-x) |
Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Intel® AES New Instructions (Intel® AES-NI) |
Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) |
Yes |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) |
Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) |
Yes |
| Intel® Identity Protection Technology (Intel® IPT) |
Yes |
| Intel® InTru™ 3D Technology |
Yes |
| Intel® Insider™ |
Yes |
| Intel® My WiFi Technology (Intel® MWT) |
Yes |
| Intel® OS Guard |
Yes |
| Intel® Quick Sync Video Technology |
Yes |
| Intel® Secure Key |
Yes |
| Intel® Small Business Advantage (Intel® SBA) |
Yes |
| Intel® Smart Response Technology |
Yes |
| Intel® Turbo Boost Technology |
2.0 |
| Processor ARK ID |
95443 |
| Processor code |
SR2ZU |
| Processor package size |
42 x 24 mm |
| Supported instruction sets |
AVX 2.0, SSE4.1, SSE4.2 |
| Thermal Monitoring Technologies |
Yes |
| Intel® Wireless Display (Intel® WiDi) |
Yes |
| Battery |
| Battery capacity |
60 Wh |
| Battery capacity |
60 Wh |
| Number of battery cells |
4 |
| Battery technology |
Lithium |
| Power |
| DC-in jack |
Yes |
| AC adapter output voltage |
19.5 V |
| AC adapter output current |
3.34 A |
| AC adapter input voltage |
100 - 240 V |
| AC adapter frequency |
50 - 60 Hz |
| AC adapter power |
65 W |
| Security |
| Password protection type |
BIOS, Supervisor, User |
| Password protection |
Yes |
| Cable lock slot type |
Noble |
| Cable lock slot |
Yes |
| Operational conditions |
| Non-operating altitude |
-15.2 - 10668 m |
| Operating altitude |
-15.2 - 3048 m |
| Storage relative humidity (H-H) |
5 - 95% |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage temperature (T-T) |
-51 - 71 °C |
| Operating temperature (T-T) |
0 - 60 °C |
| Sustainability |
| Sustainability certificates |
ENERGY STAR |
| Weight & dimensions |
| Height |
17.9 mm |
| Depth |
207.9 mm |
| Width |
304.8 mm |
| Weight |
1.18 kg |
| Packaging content |
| Manual |
Yes |
| Power cord included |
Yes |
| Quick start guide |
Yes |
| AC adapter included |
Yes |
| Other features |
| Intel segment tagging |
Home office, Small Business |
| Internal memory |
8 GB |
| Manufacturer |
DELL |
| Maximum internal memory |
16 GB |
| Operating temperature (T-T) |
0 - 60 °C |
| Maximum internal memory (64-bit) |
16 GB |
