Delta ESAJ150-EAA02 19'' 3U Add-On PV Power System
ESAJ150-EAA Series is the power system playing the leader role in Telecom industry and Data center application with 150A of the power for 48V system. It is modular, expandable and can be easily installed in 19-inch enclosure, also with high cost-performance ratio and gorgeous efficiency all rolled into one, that is, your one of a kind energy core.
To maintain all aspects of the power performance, working perfectly at extremely high efficiency and keeping low consumption, not to mention the ultra-leading power density, makes ESAJ150-EAA Series the extraordinary green design and the savior of reducing CO₂.
Relying on the advanced real time monitoring mechanism and comprehensive battery management, ensuring prevention before problems and lengthening the battery life can reach each component’s full potential in a compact 3U shelf and generate savings in OPEX.
Key Features
- Nominal input voltage 324 VDC with 50-440 VDC operating range.
- Output voltage nominal -48 VDC, default -54 VDC, adjustable -42 to -58 VDC.
- Maximum power 150 A at 54 VDC with three PVC3000B slots.
- MC4 connectors for quick, secure wiring.
- 20A-2P MCB and optional surge protective device.
- Configurable via Delta Controller for remote monitoring.
- Altitude capability up to 4000 m and humidity 5-95 % non-condensing.
- Compliance with IEC62368-1, CE, TUV/UL and RoHS standards.
Specifications
| INPUT |
|
| Voltage (nominal) |
324VDC |
| Voltage (range) |
50 - 440 VDC (operation) |
| Protection |
20A-2P MCB and SPD(optional) |
| Connections |
MC4 Connectors |
| OUTPUT |
|
| Voltage (nominal) |
-48VDC |
| Voltage (default) |
-54VDC |
| Voltage (adjustable range) |
-42 to -58VDC |
| Maximum Power @ 54VDC |
150A with 03 slots for PVC3000B |
| CONTROL AND MONITORING |
|
| Configurable with Delta Controller |
Please contact with Delta technician for detail. |
| MECHANICAL |
|
| Dimensions (W x H x D) |
481.6 x 132.6 x 367.6mm (18.96 x 5.22 x 14.47in) |
| ENVIRONMENTAL |
|
| Operating Temperature |
0 to +65 ᵒC (+32 to +149 ᵒF) |
| Storage Temperature |
-40 to +70 ᵒC (-40 to +158 ᵒF) |
| Altitude |
0 to +4000m |
| Related Humidity |
5 – 95 % RH non-condensing |
| Acoustic Noise |
≤ 60dBA @ 1M |
| STANDARDS |
|
| Safety |
Delta Standard (IEC62368-1) |
| EMC |
CE, TUV/UL (power module) |
| Environment |
RoHS |
