Winmate EACIM20 A53 Quad Core Industrial IoT Gateway 4GB RAM 32GB eMMC

Many factories and remote sites need a computer that can talk to sensors, machines and the cloud without crashing. When a gateway cannot handle the data load or cannot survive dust, heat or vibration, production stops and costs rise. The EACIM20 A53 Quad Core Industrial IoT Gateway 4GB RAM 32GB eMMC gives you a sturdy, fast and secure bridge that keeps your data flowing and your equipment running.

Winmate EACIM20 A53 Quad Core Industrial IoT Gateway 4GB RAM 32GB eMMC with EACIM20

Imagine a tiny box that can collect hundreds of sensor readings every second, turn them into useful information and send them to the cloud - all while standing up to harsh factory conditions. That is exactly what the EACIM20 does. It is built for industrial automation, remote monitoring and edge-computing tasks where reliability matters most. If you have ever struggled with slow, unreliable connections, this gateway solves the problem with a powerful quad-core processor, ample memory and a fan-less design that never overheats.

Usages

The EACIM20 fits into many real-world projects. Use it on a production line to gather data from PLCs and feed a cloud analytics platform. Deploy it in a wind farm to monitor turbine health and send alerts over LTE. Install it in a smart-city traffic camera hub to manage video streams and vehicle counts. It also works for building energy management, railway signaling and any place where a rugged edge computer is required.

Benefits

• Fast processing lets you run complex analytics at the edge.
• Fan-less design reduces maintenance and eliminates dust problems.
• Wide temperature and humidity range keeps it running in tough environments.
• Multiple mounting options let you place it on a desk, wall or DIN rail.
• Secure OS options and SOTI compliance protect your data from attacks.

Key Features

• ARM A53 Quad-Core 2.0 GHz processor for high-speed tasks.
• 4 GB LPDDR4 RAM ensures smooth multitasking.
• 32 GB eMMC storage for OS, apps and logs.
• Fanless metal enclosure with IP30 protection.
• Two Gigabit Ethernet ports for reliable wired networking.
• Optional 4G/LTE module for cellular connectivity.
• Optional WLAN and Bluetooth modules for wireless needs.
• Multiple expansion ports: RS232/422/485, CAN, digital I/O, USB.
• Android 11 (upgradeable to 13) and Linux Yocto/Ubuntu options.
• SOTI MobiControl compliance for device management.
• Operating temperature 0 C to 55 C, humidity 30 %-90 % non-condensing.
• Power input 9-36 V DC with LED power indicator.
