Small businesses and growing IT teams often struggle with slow, unreliable network connections that cause downtime and lost productivity. When the network cannot keep up with modern devices, users experience lag, video calls drop, and data transfers stall. The Extreme Networks ExtremeSwitching X465-24S Managed Rack-mountable Switch solves this by delivering fast, stable, and scalable connectivity in a compact rack-mountable design. It gives you the bandwidth and control you need to keep every workstation, server, and IoT device running smoothly.
Extreme Networks ExtremeSwitching X465-24S Managed Rack-mountable Switch with Extreme
Imagine a network that never slows you down, even when you add new devices or increase traffic. The X465-24S is a managed switch built for midsize enterprises that need reliable performance and easy management. It connects servers, workstations, cameras, and wireless APs with high-speed ports, while giving you full control through Extremes intuitive software. If you are tired of bottlenecks and need a switch that grows with your business, this product is the answer.
Key Features
- 24 x 100/1000Base-X SFP ports (unpopulated) for flexible fiber connections.
- 4 x 1/10 Gb SFP+ ports for high-speed uplinks.
- 2 x 10/25 Gb SPF28 ports for mid-range bandwidth needs.
- 1 x 40 Gb QSFP+ VIM5 slot for future expansion.
- 2 x 40 Gb QSFP+ stacking ports for easy scaling.
- Aggregated bandwidth of 316 Gbps and forwarding rate of 235.1 Mpps.
- Dual-core x86 CPU, 2 GB DRAM, 8 GB eMMC NVRAM for reliable operation.
- Rack-mount dimensions 1.70 in. H 17.34 in. W 19.23 in. D, weight 16.69 lb.
- Power range 52 W - 173 W, heat dissipation 179 - 590 BTU/hr.
- Serial console, USB-C, and two USB-A ports for local management.
- Advanced Edge License included for full Extreme EXOS features.
Specifications
| Performance and scale |
|
| Switch Model |
X465-24S |
| Max Active100Mb/1Gb/2.5Gb/5Gb ports |
24 |
| Max Active 1/10Gb SFP+ports |
4 |
Max Active
10/25Gb SPF28 ports |
2 |
Max
Active 40Gb QSFP+ VIM5 ports* |
1 |
| Max Active QSFP+ Stacking Ports |
2 |
| Aggregated Switch Bandwidth |
316Gbps |
| Frame Forwarding Rate |
235.1Mpps |
| Ports/Slots |
|
| X465-24S |
24 x 100/1000Base-X (SFP) ports (unpopulated)
2 x 40GBase-X QSFP+ dedicated stacking ports (unpopulated)
1 x Serial console port (RJ-45)
1 x 10/100/1000BASE-T out-of-band management port
1 x USB Micro-B console port
2 x USB A ports for external USB flash
1 x VIM5 slot |
| Weights and Dimensions |
|
| Weights |
7.57 kg (16.69 lb) |
| Dimensions |
Height: 43.18 mm (1.70 in.)
Width: 440.44 mm (17.34 in.)
Depth: 488.44 mm (19.23 in.) |
| Power Consumption and Heat Dissipation |
| Minimum Power Consumption |
52 W |
| Minimum Heat Dissipation |
179 BTU/hr |
| Maximum Power Consumption |
173 W |
| Maximum Heat Dissipation |
590 BTU/hr |
| CPU/Memory |
|
| X465-24S |
Dual Core x86 CPU
2GB DRAM
8GB eMMC NVRAM |
| Ordering Info |
|
| X465-24S (unbundled) |
X465-24S with 24 100/1000Base-X (SFP) ports, includes 2 fan modules, 1 VIM5 slot,
rack-mount kit, EXOS Advanced Edge License |
