You need fast, reliable wireless connectivity for modern devices, but many modules still rely on older LTE bands or bulky antennas. When a connection drops or cannot reach the required speed, your application suffers delays, lost data, and unhappy users. The Fibocom FM160-NA, 5G Sub-6 GHz M.2 Wireless Module gives you a compact, high-performance solution that supports the latest 5G bands, LTE fallback, and multiple interfaces, so you can keep your device online and fast.
Fibocom FM160-NA, 5G Sub-6 GHz M.2 Wireless Module with Fibocom
Imagine a single card that brings true 5G speed to any M.2 slot. The FM160-NA is a Sub-6 GHz 5G module that fits into standard M.2 sockets and works with Windows, Linux, or Android. It solves the common problem of limited bandwidth and spotty coverage in industrial IoT, edge computing, and mobile devices. With Fibocoms proven chipset, you get fast download up to 3.5 Gbps, reliable LTE fallback, and built-in GPS for location services.
Key Features
- Sub-6 GHz 5G bands: n2/5/12/14/25/30/41/48/66/70/71/77
- LTE FDD and TDD support for broad carrier compatibility
- NR 44 downlink MIMO and 22 uplink MIMO for strong signal
- Maximum 2470 Mbps downlink and 900 Mbps uplink in SA mode
- EN-DC speeds up to 3470 Mbps downlink and 555 Mbps uplink
- USB 3.1/3.0, USB 2.0 and PCIe 4.0 interfaces
- GPIO, UIM, I2S, MIPI ports for flexible peripheral control
- FOTA support enables remote firmware updates
- Operating system drivers for Windows, Linux, Android
- FCC/IC certification and AT&T, T-Mobile, Verizon carrier support
Specifications
| General |
|
| Product Model |
FM160-NA |
| Region |
North America |
| Frequency Band |
|
| Sub-6 |
n2/5/12/14/25/30/41/48/66/70/71/77 |
| LTE FDD |
B2/4/5/12/13/29/30/66/71 |
| LTE TDD |
B41/46(LAA)/48 |
| Key Functions |
|
| NR MIMO |
DL 4x4MIMO: n2/5/12/14/25/30/41/48/66/70/71/77; UL 2x2MIMO: n41/77 |
| LTE MIMO |
DL 4x4MIMO: B2/4/5/12/13/30/41/48/66/71 |
| NR SA (Mbps) |
2470(DL) / 900(UL) |
| NR ENDC (Mbps) |
3470(DL) / 555(UL) |
| LTE (Mbps) |
1600(DL) / 211(UL) |
| WCDMA (Mbps) |
NA |
| Functions |
|
| Voice |
VoLTE & VoNR(Optional) |
| SMS |
SMS over IP(IMS) |
| Audio |
Supported |
| FOTA |
Supported |
| OS Drivers |
Windows/Linux/Android |
| GNSS |
GPS/GLONASS/Galileo/BeiDou/QZSS |
| Interfaces |
|
| USB |
USB3.1/3.0 & USB2.0 |
| PCIe |
PCIe4.0 |
| UART |
NA |
| SPI |
NA |
| GPIO |
Supported |
| I2C |
NA |
| SDIO |
NA |
| UIM |
Supported |
| I2S |
Supported |
| MIPI |
Supported |
| RGMII |
NA |
| Certification |
|
| Regulation |
FCC/IC |
| Operator |
AT&T/TMO/Verizon |
| Industry |
PTCRB/GCF |
