When you need a powerful computer that fits into a tiny space, many developers struggle with bulky boards that waste space and drain power. In industrial or edge-AI projects, size, speed and reliability are critical because a delay can stop a production line or break a smart camera feed. The Firefly CAM-3576Q38(Commercial) gives you a 38 mm board that delivers octa-core performance, a 6 TOPS NPU and real-time Linux, all in a lightweight package.
Firefly CAM-3576Q38(Commercial), 4GB/64GB 38mm Mini Single Board Computer with Firefly
Meet the Firefly CAM-3576Q38(Commercial), 4GB/64GB 38mm Mini Single Board Computer with Firefly - the tiny engine that powers your next AI edge device. This board packs a Rockchip RK3576 SoC, eight cores up to 2.2 GHz and a Mali-G52 GPU, so you can run video analytics, robotics control or digital signage without a full-size PC. If you have ever been limited by slow processing or missing AI acceleration, this board removes that barrier and lets you build fast, reliable systems.
Key Features
- Rockchip RK3576 SoC with 4 Cortex-A72 + 4 Cortex-A53 cores.
- Octa-core processor up to 2.2 GHz for fast computation.
- Mali-G52 MC3 GPU at 1 GHz supporting OpenGL ES, OpenCL and Vulkan.
- 6 TOPS NPU supporting INT4, INT8, INT16, FP16, BF16 and TF32.
- LPDDR4/LPDDR4x/LPDDR5 memory options up to 16 GB.
- eMMC storage up to 256 GB plus a TF card slot for expansion.
- 100 M Ethernet via 8P-1.25 mm wafer connector.
- Dual reset and MaskRom buttons for easy debugging.
Specifications
| SoC |
CAM-3576Q38: Rockchip RK3576 |
| CPU |
CAM-3576Q38: Octa-core 64-bit processor (4× Cortex-A72 + 4× Cortex-A53), up to 2.2GHz |
| GPU |
ARM Mali-G52 MC3 @ 1GHz, supports OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1, with high-performance
2D acceleration hardware
|
| NPU |
6 TOPS NPU, supports INT4, INT8, INT16, FP16, BF16, TF32; dual-core collaborative or independent operation; supports
multi-task and multi-scene parallel processing
|
| Memory |
LPDDR4 / LPDDR4x / LPDDR5 (4GB, 8GB, 16GB optional) |
| Storage |
eMMC (16GB, 32GB, 64GB, 128GB, or 256GB optional) |
| Storage Expansion |
1 × TF Card slot |
| Power Supply |
DC 12V (via 8P-1.25mm Wafer connector) |
| Operating System |
Supports RTLinux kernel with real-time performance for industrial applications; supports Linux and Buildroot;
includes industrial features such as real-time networking, FlexBus, hardware resource isolation, and DSMC
|
| Dimensions |
38.09 × 38.11 × 11.54 mm |
| Weight |
Approx. 21g |
| Operating Environment |
CAM-3576Q38: Operating temperature: -20°C to 60°C; Storage humidity: 10%–90% RH (non-condensing) |
| Ethernet |
1 × 100M Ethernet (LED routed via 8P-1.25mm Wafer connector) |
| Buttons |
1 × Reset, 1 × MaskRom |
