Imagine trying to find a hidden fault in a circuit and only getting a vague beep. You need a clear picture, not a guess. The Fluke ScopeMeter 190-062-III Test Tool gives you a full-color LCD display and two isolated channels so you can see exactly what is happening on your wires. It solves the frustration of missed glitches and saves you time on every repair.
Fluke ScopeMeter 190-062-III Test Tool, 2 Channel 60MHz Full-color LCD
When a signal is too fast or too small, many handheld tools simply cannot capture it. Missing that detail can cause equipment downtime and extra cost. This ScopeMeter captures fast events up to 60 MHz with a real-time rate of 625 MS/s, so you never lose a pulse again. The clear color screen and built-in analysis functions turn raw data into easy decisions, letting you fix problems the first time.
Key Features
- 60 MHz bandwidth for high-frequency signals.
- 625 MS/s real-time sampling on both channels.
- 8-bit vertical resolution for clear waveform detail.
- Fully floating, isolated inputs (CAT III 1000 V / CAT IV 600 V).
- Multiple trigger types including edge, pulse width, and video.
- Glitch capture down to ~8 ns.
- ScopeRecord deep memory with 30,000 samples per channel.
- TrendPlot long-term logging for temperature or voltage trends.
- USB data transfer and optional Wi-Fi for easy sharing.
- Rechargeable Li-ion battery with about 7 hours runtime.
Specifications
| Model |
ScopeMeter 190-062-III Test Tool |
| Part Number |
5282331 |
| Series |
Fluke 190 Series III ScopeMeter |
| Display |
Color LCD display |
| Channels |
2 electrically isolated input channels + external trigger |
| Bandwidth |
60 MHz |
| Real-time sampling rate |
Up to 625 MS/s (simultaneous) |
| Vertical resolution |
8-bit |
| Input architecture |
Fully floating, isolated inputs (independent from ground) |
| Safety rating |
CAT III 1000 V / CAT IV 600 V |
| Input coupling |
AC or DC with ground reference indicator |
| Input impedance |
1 MΩ ±1% // ~15 pF |
| Input sensitivity |
2 mV/div to 100 V/div (with probes) |
| Timebase range |
10 ns/div to 2 min/div |
| Trigger types |
Connect-and-View™, edge, pulse width, video, delay, dual slope, single shot |
| Glitch capture |
Down to ~8 ns |
| Maximum record length (ScopeRecord mode) |
30,000 samples per channel |
| Waveform functions |
Persistence display, waveform compare, Pass/Fail testing |
| DMM mode (meter inputs) |
Fully isolated 4 mm banana inputs |
| Meter resolution |
5,000 counts |
| Voltage ranges (DMM) |
500 mV to 1,100 V |
| Resistance ranges (DMM) |
500 Ω to 30 MΩ |
| Continuity / diode test |
Yes |
| Current measurement |
Via external current clamps/shunts (scaled inputs) |
| Temperature measurement |
With optional probes |
| Recorder mode |
ScopeRecord™ deep memory waveform capture |
| Trend logging |
TrendPlot™ long-term measurement recording |
| Interfaces |
USB (data transfer), optional WiFi depending kit |
| Memory |
Internal memory for waveform and trend storage |
| Operating temperature |
0 °C to 50 °C |
| Storage temperature |
-20 °C to 60 °C |
| Enclosure rating |
IP51 |
| Battery |
Rechargeable Li-ion battery pack |
| Battery runtime |
Approx. 7 hours (typical, depends on use) |
| Weight |
~1.5 kg (with battery) |
| Dimensions |
~259 × 132 × 55 mm |
| Included accessories (typical kit) |
HV probes (VPS421), test leads, battery pack, charger, USB cable, hanging strap, carrying case |
