Imagine a small box that can run heavy AI models, process multiple video streams, and still fit on a factory shelf. The Forlinx FCU3011, NVIDIA Jetson Orin Nano CPU, AI Edge Computing Box does exactly that. It is built for developers and engineers who need fast AI inference at the edge without the hassle of a large server. If you struggle with slow cloud responses or bulky hardware, this box gives you the power you need right where you need it.
Forlinx FCU3011, NVIDIA Jetson Orin Nano CPU, AI Edge Computing Box
Many edge projects fail because the processor cannot handle real-time video or AI tasks. The result is lag, missed detections, and lost productivity. This matters to you because every second of delay can cost money or safety. The Forlinx box solves the problem with a 6-core Arm Cortex-A78AE CPU, an NVIDIA Ampere GPU, and up to 40 TOPS of AI performance. It delivers instant inference, multiple 4K streams, and reliable networking, all in a fanless, rugged package.
Key Features
- NVIDIA Jetson Orin Nano processor with 6-core Arm Cortex-A78AE CPU.
- GPU with 1024 CUDA cores and 32 Tensor Cores for AI workloads.
- 40 TOPS AI performance in the 8 GB model.
- 8 GB LPDDR5 RAM and 128 GB PCIe x4 NVMe SSD storage.
- Four Gigabit Ethernet ports with ESD protection.
- Supports 5G or 4G modules via M.2 slot for cellular connectivity.
- Two USB 3.0 and two USB 2.0 ports, all ESD protected.
- HDMI 2.0 output supports up to 4K display.
- Industrial I/O: RS-485, CAN, two relay outputs, two isolated inputs.
- Passive heat dissipation, fanless enclosure for harsh environments.
Specifications
| Processor |
|
| Processor |
NVIDIA Jetson Orin Nano |
| CPU |
6-core Arm® Cortex®-A78AE v8.2 64-bit CPU |
| GPU |
NVIDIA Ampere architecture GPU |
| GPU (8GB Model) |
1024 NVIDIA® Ampere CUDA cores, 32 Tensor Cores |
| Hardware Encoding |
1080p30 |
| Hardware Decoding |
1 × 4K60 (H.265), 2 × 4K30 (H.265), 5 × 1080p60 (H.265), 11 × 1080p30 (H.265) |
| AI Performance |
|
| 4GB Model |
20 TOPS |
| 8GB Model |
40 TOPS |
| Memory |
|
| RAM |
8GB LPDDR5 |
| Storage |
|
| ROM |
128GB PCIe x4 NVMe SSD |
| TF Card |
Supports storage expansion |
| Networking |
|
| Ethernet |
4 × Gigabit Ethernet ports (10/100/1000 Mbps auto-adaptive), ESD Level 3 protection |
| Wi-Fi |
1 × M.2 PCIe x1 2230 Key E standard interface |
| 4G / 5G |
Supports Quectel RM500U 5G module or Quectel EM05 4G module |
| USB |
|
| USB Ports |
2 × USB 3.0, 2 × USB 2.0, all with ESD Level 3 protection |
| Display |
|
| HDMI |
1 × HDMI 2.0, supports up to 4K display |
| Industrial Interfaces |
|
| RS-485 |
1 × RS-485, 3KV isolation protection, ESD Level 3 protection |
| CAN |
1 × CAN, 2.5KV isolation protection, ESD Level 3 protection |
| Switching Output |
2 × Relay outputs, Contact capacity: 5A 30VDC / 5A 250VAC |
| Switching Input |
2 × Inputs, 2.5KV opto-isolation |
| System |
|
| Real-Time Clock |
Built-in CR2032 battery |
| Recovery Button |
1 × System recovery button |
| Power |
|
| Working Voltage |
Rated 12V DC, supports 9V–24V DC wide input, reverse-connection protection, over-current protection |
| Environmental |
|
| Operating Temperature |
0°C ~ +60°C |
| Cooling |
Passive heat dissipation, fanless design |
| Operating System |
|
| OS |
Forlinx Desktop 22.04 |
| Mechanical |
|
| Dimensions |
178 × 110 × 55 mm |
