The Naddod OSFP-800G-DR8P Cisco Compatible 800G Optical Transceiver Module provides high-speed 800G Ethernet connectivity over single-mode fiber. With a 1310nm wavelength, 500m reach, and OSFP form factor, it is designed for high-bandwidth data networking applications.
Naddod OSFP-800G-DR8P Cisco Compatible 800G 1310nm SMF Optical Transceiver
Designed for demanding high-speed networking environments, the OSFP-800G-DR8P supports 8x106.25Gb/s PAM4 electrical and optical modulation for 800G Ethernet connections. Its EML transmitter and PIN receiver provide the optical interface, while the MPO/MTP-16 APC connector supports multi-lane optical connectivity over SMF.
The module offers a 500m transmission distance at 1310nm, making it suitable for high-capacity links within data centers, enterprise networks, and other Ethernet infrastructure. Its ≤16W power consumption and 0°C to 70°C case temperature range support deployment in high-performance networking environments.
The transceiver can be used for 800G Ethernet network connections, data center interconnects, high-speed switch-to-switch links, and bandwidth-intensive network infrastructure where compatible 800G optical connectivity is required. Its OSFP design helps support high-density networking equipment while its Cisco compatibility makes it suitable for compatible Cisco networking platforms.
Benefits include high bandwidth, fast data transmission, 500m SMF reach, multi-lane PAM4 optical connectivity, and compatibility with high-performance 800G Ethernet infrastructure. The module is particularly useful where network operators need to upgrade links to 800G capacity while maintaining an optical fiber-based connection.
Key Features
- 800G Ethernet compliant
- Cisco compatible optical transceiver
- OSFP form factor for high-density networking
- 1310nm wavelength
- 500m transmission distance
- Supports single-mode fiber (SMF)
- MPO/MTP-16 APC connector
- 8x106.25Gb/s PAM4 electrical modulation
- 8x106.25Gb/s PAM4 optical modulation
- EML transmitter for optical transmission
- PIN receiver for optical reception
- ≤16W power consumption
- 0°C to 70°C (32°F to 158°F) case temperature range
- Suitable for 800G Ethernet connectivity, data centers, high-speed networking, and switch interconnects
