| MAIN FEATURES |
|
| One-Touch Recording |
Big button, one-touch to record |
| Connectivity |
4G, WiFi, Bluetooth, real-time communication support |
| Positioning |
GPS / Beidou / GLONASS |
| Recording Time |
9.5 hrs recording with one battery (1080p), battery replacement without shutdown |
| Display |
2.4-inch color touch screen |
| Video Resolution |
1920×1080@30FPS, 1280×720@30FPS, 840×480@30FPS |
| Image Resolution |
Main Camera: 48MP |
| USB Type |
Type-C USB |
| Alert Light |
Red & Blue light for alert attention |
| DESIGN |
|
| Dimensions |
100 × 60 × 30 mm |
| Weight |
147 g |
| Display |
2.4-inch color touchscreen |
| Key Buttons |
Photograph, Video Record, Audio Record, PTT, Power, Return, Volume, Light |
| LED Indicator |
Yes |
| Red & Blue Alert Light |
Yes |
| USB |
Type-C |
| WIRELESS CONNECTIVITY |
|
| 2G/3G/4G |
Yes |
| GPS |
Yes |
| Bluetooth |
Yes |
| WiFi |
Yes |
| SIM Slot |
Single Nano-SIM card slot |
| CAMERA |
|
| Field of View |
110° horizontal wide angle, low distortion |
| Encoding & Format |
MP4 (H.264) |
| Night Vision |
Visible up to 10 meters |
| Infrared Light |
2 infrared lights, auto/manual switch |
| Exposure/White Balance |
Auto |
| RECORDING |
|
| Video Resolution |
1920×1080@30FPS, 1280×720@30FPS, 840×480@30FPS |
| Video Format |
MP4 (H.264) |
| Audio Format |
WAV |
| Image Resolution |
Main: 48MP, 36MP, 32MP, 20MP, 16MP; Vice Camera: 5MP |
| Image Format |
JPEG |
| Pre/Post Event Recording |
Supported |
| File Tagging |
Supported |
| BATTERY |
|
| Battery Capacity |
3800mAh replaceable lithium-ion battery |
| Charging Time |
Less than 3 hours |
| Continuous Working Time |
9.5 hrs (one battery, 1080p), 19 hrs (two batteries, 1080p) |
| Backup Battery |
60mAh built-in battery (5 minutes support during replacement) |
| Low Battery Alert |
Supported |
| APPROVALS AND ENVIRONMENTAL |
|
| Dust/Water Protection |
IP67 |
| Drop Test |
2 meters |
| Operating Temperature |
-30°C to +55°C |
| Operating Humidity |
≤95% |
| SOFTWARE FEATURES |
|
| Browsing/Playback |
Video, audio, and photos searchable by date/time |
| Watermark |
Department ID, User ID, date/time, GPS coordinates overlay |
| Unique ID |
7-digit device ID, 6-digit user ID |
| Log Record |
Records on/off time, video, recording, and operations |
| SOS Alarm |
Sends GPS and real-time video to IDEM system for assistance |
| Key File Marking |
One-click file marking and retrieval in IDEM platform |
| Intercom/PTT |
Optional 2-way audio intercom between device and platform |
