Product Code: TEVP-008
MPN #: DP752
Tired of dropped calls and limited phone lines in a busy office? The Grandstream DP752, 10-Line Long-range DECT VoIP Base Station gives you crystal-clear voice quality and the ability to connect up to ten SIP accounts without wiring each desk. It solves the common problem of crowded desk phones and unreliable wireless range, so you can answer every customer call on time.
Many small and medium businesses struggle with limited phone capacity and short-range cordless handsets. When a call cannot be answered, sales are lost and service suffers. The DP752 removes that bottleneck by supporting ten simultaneous SIP lines and delivering up to 350 m outdoor range. You get a single base that handles many handsets, so every employee can stay connected without extra cabling.
| Telephony Standards | |
|---|---|
| Telephony Standards | DECT |
| Frequency Bands |
1880 – 1900 MHz (Europe), 1920 – 1930 MHz (US), 1910 – 1920 MHz (Brazil), 1786 – 1792 MHz (Korea), 1893 – 1906 MHz (Japan), 1880 – 1895 MHz (Taiwan) |
| Number of Channels | 10 (Europe), 5 (US, Brazil or Japan), 3 (Korea), 8 (Taiwan) |
| Outdoor Range | up to 400 meters (DP730/DP725/DP735) or up to 350 meters (DP722/DP720) |
| Indoor Range | up to 50 meters |
| Energy Saving | ECO Mode |
| Peripherals | |
| LED Indicators | 3 LED indicators: Power, Network, DECT |
| Pairing/Paging | Pairing/Paging button |
| Ethernet Port | One 10/100 Mbps auto-sensing Ethernet port |
| PoE | integrated PoE |
| Protocol/Standards | |
| Protocols/Standards |
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP/RARP, ICMP, DNS (A record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP-MED, LDAP, TR-069, 802.1x, TLS, SRTP |
| Voice Codecs | |
| Voice Codecs |
G.711μ/a-law, G.723.1, G.729A/B, G.726-32, iLBC, G.722, OPUS, in-band and out-of-band DTMF(in audio, RFC2833, SIP INFO), VAD, CNG, PLC, AJB |
| Telephony Features | |
| Call Features | Hold, transfer, forward, 3-way conference |
| Phonebook | downloadable phonebook (XML, LDAP, up to 3000 entries) |
| Call Waiting | call waiting |
| Call Log | call log (up to 750 records) |
| Auto Answer | auto answer |
| Dial Plan | flexible dial plan |
| Server Redundancy | server redundancy and fail-over |
| QoS | |
| Layer 2 QoS | Layer 2 QoS (802.1Q, 802.1P) |
| Layer 3 QoS | Layer 3 QoS (ToS, DiffServ, MPLS) |
| Security | |
| Access Control | User and administrator level access control |
| Authentication | MD5 and MD5-sess based authentication |
| Configuration File | 256-bit AES encrypted configuration file |
| TLS | TLS |
| SRTP | SRTP |
| HTTPS | HTTPS |
| Media Access Control | 802.1x media access control |
| DECT Security | DECT authentication & encryption |
| Multi-language | |
| Languages |
English, Czech, German, Spanish, French, Hebrew, Italian, Dutch, Polish, Portuguese, Russian, Turkish, Arabic, Chinese Simple, Chinese Tradition, Japanese, Korean, Slovakian, Serbian |
| Upgrade/Provisioning | |
| Firmware Upgrade | Firmware upgrade via TFTP/HTTP/HTTPS |
| Mass Provisioning | mass provisioning using TR-069 or AES encrypted XML configuration file |
| Multiple SIP Accounts | |
| SIP Accounts | Up to ten (10) distinct SIP accounts per system |
| Handset Mapping | Each handset may map to any SIP account(s) |
| SIP Account Mapping | Each SIP account may map to any handset(s) |
| Ring Group | |
| Circular Mode | all phones ring sequentially from the phone next to the one that answered last |
| Linear Mode | all phones ring sequentially in the predesignated order |
| Parallel Mode | all phones ring concurrently and after one phone answers, the remaining available phones can make new calls |
| DID Call Group | multiple handsets can call out on the same account, but all incoming calls are directed to a single handset |
| Power & Green Energy Efficiency | |
| Universal Power Supply | Input AC 100-240V 50/60Hz; Output 5VDC 1A; Micro-USB connection |
| PoE | IEEE802.3af Class 1, 0.44W–3.84W |
| Package Content | |
| Package Content | Base Unit, Universal Power Supply; Ethernet cable; Quick Start Guide, GPL statement |
| Dimensions | |
| Dimensions (H x W x D) | 140.31 x 64.98 x 105mm |
| Weight | |
| Base Unit | 140g |
| Universal Power Supply | 50g |
| Package | 370g |
| Temperature and Humidity | |
| Operation | -10 to 50ºC (14 to 122ºF) |
| Storage | -20º to 60ºC (-4 to 140ºF) |
| Humidity | 10% to 90% non-condensing |
| Compliance | |
| Compliance | FCC, CE, RCM, IC |
