| Protocols/Standards |
|
| SIP |
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, RTCP-XR, TLS, SRTP |
| Network |
IPv4, IPv6, HTTP/HTTPS, ARP, ICMP, DNS(A record, SRV, NAPTR), DHCP, SSH, TFTP, NTP, STUN, LLDP, TR-069, 802.1x |
| Graphic Display |
|
| Screen Size |
3.5” |
| Display Type |
High-Resolution Color LCD |
| Resolution |
480x320 |
| Network Interfaces |
|
| Ethernet Port |
One auto-negotiation 10/100 Mbps ethernet port |
| PoE |
integrated PoE Class 2 |
| Wi-Fi |
|
| Wi-Fi |
GHP630W integrated dual-band 2.4GHz & 5GHz 802.11 a/b/g/n/ac/ax |
| Feature Keys |
|
| Total Keys |
26 keys, including: |
| Context-Sensitive Soft Keys |
6 Context-Sensitive Soft keys |
| Standard Phone Digits Keys |
12 Standard Phone Digits keys (0-9: speed dial keys configuration on web page, * , #) |
| Function Keys |
5 Function keys (Flash, Redial, Hands-free, Voice Mail, Hold) |
| Volume Control Keys |
3 Volume Control keys, Up/Down/Mute (with red color LED) |
| HD Audio |
|
| HD Handset |
One HD handset support for wide band audio |
| Voice Conferencing |
|
| SIP Accounts and Lines |
2 SIP accounts and lines |
| Conference |
up to 3-way conference |
| Telephony Features |
|
| Call Features |
Dial, Answer, Redial, Flash ,Hands-free, Voice Mail(with the server), Transfer, Conference, Hold /Unhold, Mute /Unmute |
| Dial Plan |
flexible dial plan |
| Speed Dial |
Speed dial |
| Server Redundancy |
server redundancy & fail-over |
| Call Out |
Call out |
| Advanced Features |
|
| Multicast Paging and E911 |
Support for multicast paging and E911 service. |
| GDS Door Opening |
Support GDS Door opening. |
| Jitter-Resilience |
Support for advanced jitter-resilience algorithm. |
| USB |
|
| USB Port |
USB Type-C port for charging external devices (500mA MAX) |
| Wall Installation |
|
| Wall Mount |
1 Wall Mountable Base |
| QoS |
|
| Layer 2 QoS |
Layer 2 QoS (802.1Q, 802.1p) |
| Layer 3 QoS |
Layer 3 (ToS, DiffServ, MPLS) QoS |
| Security |
|
| Secure Boot |
Secure boot |
| Default Password |
random default password |
| Security Certificate |
unique security certificate per device |
| Passwords |
administrator level passwords |
| Configuration File |
256-bit AES encrypted configuration file |
| SRTP |
SRTP |
| TLS |
TLS |
| Media Access Control |
802.1x media access control |
| Multi-language |
|
| Languages |
English, Spanish, French, Chinese (pending) |
| Upgrade/Provisioning |
|
| Firmware Upgrade |
Firmware upgrade via FTP / TFTP / HTTP / HTTPS |
| Boot |
fast boot in 15 seconds |
| Mass Provisioning |
mass provisioning using GDMS/TR-069 or AES encrypted XML configuration file |
| Power & Green Energy Efficiency |
|
| Power Adapter |
Universal power adapter |
| Input |
100~240Vac 50~60Hz |
| Output |
12V/0.5A(6W) |
| Temperature and Humidity |
|
| Operation |
0°C to 40°C |
| Storage |
-10°C to 60°C |
| Humidity |
10% to 90% (Non-condensing) |
| Package Content |
|
| Package Content |
GHP phone, handset with cord, Base Stand, universal power supply (GHP630W, GHP631W), Quick Installation Guide |
| Color |
|
| Color |
White (GHP630,GHP630W), Black (GHP631,GHP631W) |
| Physical |
|
| Unit Size |
210mm(L)*147mm(W)*89.8mm(H) (with handset and base stand) |
| Unit Weight |
668g |
| Package Weight |
881g |
