| Performance |
| Languages support |
Simplified Chinese, Czech, German, Dutch, English, Spanish, French, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Turkish |
| Number of languages |
17 |
| Alarm input/output |
Yes |
| Day/night mode |
Yes |
| Wide Dynamic Range (WDR) |
Yes |
| Connectivity technology |
Wired |
| Placement supported |
Indoor |
| Type |
IP security camera |
| Design |
| Housing material |
Plastic |
| Product colour |
White |
| Mounting type |
Ceiling |
| Form factor |
Dome |
| Camera |
| Camera shutter speed |
(1/5 - 1/12000 s |
| Camera shutter type |
Electronic |
| White balance |
ATW, AWC, Indoor, Manual, Outdoor |
| Pan range |
0 - 350° |
| Tilt angle range |
0 - 67° |
| Angle of rotation |
355° |
| Minimum illumination |
0.095 lx |
| Camera tilt control |
Yes |
| Camera pan control |
Yes |
| Image sensor |
| Number of effective pixels (H x V) |
1920 x 1080 pixels |
| Optical sensor size |
25.4 / 2.8 mm (1 / 2.8") |
| Sensor type |
CMOS |
| Lens system |
| Focus |
Motorized |
| Focal length range |
3.2 - 10 mm |
| Optical zoom |
3.1x |
| Zoom capability |
Yes |
| Night vision |
| Night vision |
No |
| Video |
| Back Light Compensation (BLC) |
Yes |
| Bit rate control |
Constant Bit Rate (CBR)/Variable Bit Rate (VBR), Variable Bit Rate (VBR) |
| Privacy masking |
Yes |
| Noise reduction |
Yes |
| Frame rate |
30 fps |
| Supported graphics resolutions |
640 x 360, 720 x 480, 720 x 576, 800 x 448, 800 x 600 (SVGA), 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080) |
| Video compression formats |
H.264, H.265, M-JPEG |
| Video formats supported |
H.264, H.265, M-JPEG |
| Total megapixels |
2 MP |
| Maximum resolution |
1920 x 1080 pixels |
| Audio |
| Built-in microphone |
Yes |
| Sample rate |
8 kHz |
| Audio formats supported |
G.711, G.726 |
| Network |
| Quality of Service (QoS) support |
Yes |
| Streaming method |
Multicast, Unicast |
| Number of users |
6 user(s) |
| Supported network protocols |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP |
| Ethernet interface type |
Fast Ethernet |
| Bluetooth |
No |
| Wi-Fi |
No |
| Ethernet LAN |
Yes |
| Storage |
| Internal memory |
512 MB |
| Flash memory |
256 MB |
| Maximum memory card size |
128 GB |
| Compatible memory cards |
MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Card reader integrated |
Yes |
| Built-in HDD |
No |
| Ports & interfaces |
| DC-in jack |
Yes |
| Composite video out |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| Security |
| Active tampering alarm |
Yes |
| Alert notification type |
E-mail |
| Anti-flicker |
Yes |
| IP address filtering |
Yes |
| Intelligent Video Surveillance (IVS) system features |
Defocus, People counting |
| Security algorithms |
EAP-TLS, HTTPS, LEAP, SSL/TLS |
| Video motion detection |
Yes |
| Password protection type |
User |
| Password protection |
Yes |
| Management features |
| Web-based management |
Yes |
| Power |
| Power consumption (Power over Ethernet (PoE)) |
6 W |
| Power consumption (max) |
6.5 W |
| Power consumption (typical) |
5.1 W |
| Power source type |
DC, PoE |
| Operational conditions |
| Storage relative humidity (H-H) |
5 - 90% |
| Operating relative humidity (H-H) |
5 - 90% |
| Storage temperature (T-T) |
-30 - 60 °C |
| Operating temperature (T-T) |
-10 - 55 °C |
| System requirements |
| Mac operating systems supported |
Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave |
| Windows operating systems supported |
Windows 10, Windows 7, Windows 8, Windows 8.1 |
| Weight & dimensions |
| Weight |
320 g |
| Diameter |
12 cm |
| Height |
98.8 mm |
| Supplier features |
| Manufacturer |
Hanwha |
| Packaging content |
| Number of cameras |
1 |
| Other features |
| Maximum resolution |
1920 x 1080 pixels |
