| Performance |
| Certification |
FCC (47 CFR 15, B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) UL (UL 60950-1); CB (IEC 60950-1: 2005 + Am 1: 2009 + Am 2: 2013, IEC 62368-1: 2014 ); CE-LVD (EN 60950-1: 2005 + Am 1: 2009 + Am 2: 2013, IEC 62368-1: 2014 ); BIS (IS 13252(Part 1): 2010+A1: 2013+A2: 2015); LOA (IEC/EN 60950-1) CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach ((EC) No 1907/2006) |
| Number of languages |
33 |
| Alarm input/output |
Yes |
| Day/night mode |
Yes |
| Infrared (IR) cut-off filter |
Yes |
| Wide Dynamic Range (WDR) |
Yes |
| Connectivity technology |
Wired |
| Placement supported |
Outdoor |
| Type |
IP security camera |
| Design |
| International Protection (IP) code |
IP67 |
| Housing material |
Metal |
| Product colour |
Black |
| Mounting type |
Ceiling/wall |
| Form factor |
Turret |
| Camera |
| Camera shutter speed |
1/3 - 1/100000 s |
| Pan range |
0 - 360° |
| Tilt angle range |
0 - 75° |
| Lens viewing angle, diagonal |
123° |
| Lens viewing angle, vertical |
55° |
| Lens viewing angle, horizontal |
103° |
| Angle of rotation |
360° |
| Minimum illumination |
0 lx |
| Camera tilt control |
Yes |
| Camera pan control |
Yes |
| Image sensor |
| Progressive scan |
Yes |
| Optical sensor size |
25.4 / 3 mm (1 / 3") |
| Number of sensors |
1 |
| Sensor type |
CMOS |
| Lens system |
| Detect distance (wide) |
60 m |
| Fixed focal length |
2.8 mm |
| Identify distance (wide) |
6 m |
| Observe distance (wide) |
23.8 m |
| Recognize distance (wide) |
12 m |
| Maximum aperture number |
1.4 |
| Number of lenses |
1 |
| Night vision |
| LED type |
IR |
| Night vision distance |
30 m |
| Night vision |
Yes |
| Video |
| Back Light Compensation (BLC) |
Yes |
| Bit rate |
32 Kbps - 8 Mbps |
| Bit rate control |
Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Highlight Compensation (HLC) |
Yes |
| Image quality adjustment |
Brightness, Contrast, Saturation, Sharpness |
| Privacy masking |
Yes |
| Region of Interest (ROI) encoding |
Yes |
| Noise reduction technology |
3D noise reduction |
| Noise reduction |
Yes |
| Video streaming |
Yes |
| Frame rate |
30 fps |
| Supported graphics resolutions |
640 x 360, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2688 x 1520 |
| Video compression formats |
H.264, H.264+, H.265, H.265+, M-JPEG |
| Total megapixels |
4 MP |
| Maximum resolution |
2688 x 1520 pixels |
| Audio |
| Voice codecs |
AAC, G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, PCM |
| Built-in microphone |
Yes |
| Sample rate |
48 kHz |
| Audio formats supported |
MP3 |
| Built-in speaker(s) |
Yes |
| Network |
| Quality of Service (QoS) support |
Yes |
| Number of users |
32 user(s) |
| Supported network protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP |
| Networking standards |
IEEE 802.1x, IEEE 802.3af |
| Ethernet interface type |
Fast Ethernet |
| Bluetooth |
No |
| Wi-Fi |
No |
| Ethernet LAN |
Yes |
| Storage |
| Maximum memory card size |
256 GB |
| Compatible memory cards |
MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Card reader integrated |
Yes |
| Built-in HDD |
No |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
1 |
| Security |
| Anti-flicker |
Yes |
| HTTPS encryption |
Yes |
| Heartbeat |
Yes |
| IP address filtering |
Yes |
| Intelligent Video Surveillance (IVS) system features |
Scene change |
| Mirror |
Yes |
| Video motion detection |
Yes |
| Password protection |
Yes |
| Management features |
| Behavior analysis |
Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection |
| Reset button |
Yes |
| Web-based management |
Yes |
| Power |
| DC output current |
0.65 A |
| DC output voltage |
12 |
| Power consumption (Power over Ethernet (PoE)) |
8.8 W |
| Power consumption (max) |
7.8 W |
| Power source type |
DC, PoE |
| Operational conditions |
| Storage relative humidity (H-H) |
0 - 95% |
| Operating relative humidity (H-H) |
0 - 95% |
| Storage temperature (T-T) |
-30 - 60 °C |
| Operating temperature (T-T) |
-30 - 60 °C |
| Weight & dimensions |
| Weight |
825 g |
| Diameter |
13.8 cm |
| Height |
124.5 mm |
| Packaging data |
| Package weight |
1.12 kg |
| Package height |
150 mm |
| Package depth |
170 mm |
| Package width |
170 mm |
| Supplier features |
| Manufacturer |
Hikvision |
| Sustainability |
| Compliance certificates |
RoHS |
| Packaging content |
| Number of cameras |
1 |
| Other features |
| Maximum resolution |
2688 x 1520 pixels |
