| Camera |
|
| Image Sensor |
1/2" Progressive Scan CMOS |
| Max. Resolution |
3840 × 2160 |
| Min. Illumination |
Color: 0.009 Lux @ (F1.2, AGC ON), B/W: 0.0009 Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Shutter Time |
1 s to 1/100,000 s |
| Day & Night |
IR cut filter |
| Lens |
|
| Lens Type |
Varifocal lens, 8 to 32 mm |
| Focal Length & FOV |
horizontal FOV 42° to 15°, vertical FOV 23° to 8°, diagonal FOV 49° to 17° |
| Lens Mount |
Integrated |
| Focus |
Auto, semi-auto, manual |
| Iris Type |
Auto-iris, DC drive |
| Aperture |
F1.7, constant F1.7 throughout the zoom range |
| Pixel Density |
|
| DORI |
D: 580 m, O: 230.2 m, R: 116 m, I: 58 m |
| Illuminator |
|
| Supplement Light Type |
IR |
| Supplement Light Range |
8 to 32 mm: up to 100 m |
| IR Wavelength |
850 nm |
| Video |
|
| Main Stream |
50 Hz: 25 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720);
60 Hz: 30 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720)
|
| Sub-Stream |
50 Hz: 25 fps (704 × 576, 640 × 480); 60 Hz: 30 fps (704 × 480, 640 × 480) |
| Third Stream |
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480);
60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
|
| Fourth Stream |
50 Hz: 25 fps (704 × 576, 640 × 480); 60 Hz: 30 fps (704 × 480, 640 × 480) |
| Fifth Stream |
50 Hz: 25 fps (704 × 576, 640 × 480); 60 Hz: 30 fps (704 × 480, 640 × 480) |
| Video Compression |
Main stream: H.265+/H.265/H.264+/H.264; Sub-stream/Fourth stream/Fifth stream: H.265/H.264/MJPEG;
Third stream: H.265/H.264
|
| Video Bit Rate |
32 Kbps to 16 Mbps |
| H.264 Type |
Baseline Profile/Main Profile/High Profile |
| H.265 Type |
Main Profile |
| Bit Rate Control |
CBR,VBR |
| Scalable Video Coding (SVC) |
H.265 and H.264 encoding |
| Region of Interest (ROI) |
5 fixed regions for each stream |
| Target Cropping |
Yes |
| Audio |
|
| Audio Type |
Mono sound |
| Audio Compression |
G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC/MP3 |
| Audio Bit Rate |
64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/
16 to 64 Kbps (AAC-LC)/8 to 320 Kbps (MP3)
|
| Audio Sampling Rate |
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Environment Noise Filtering |
Yes |
| Image |
|
| Image Parameters Switch |
Yes |
| Image Settings |
Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance,
adjustable by client software or web browser
|
| Day/Night Switch |
Day, Night, Auto, Schedule, Alarm Trigger (-S), Video Trigger |
| Wide Dynamic Range (WDR) |
120 dB |
| SNR |
≥ 52 dB |
| Image Stabilization |
EIS |
| Image Enhancement |
BLC, HLC, Defog, 3D DNR |
| Picture Overlay |
LOGO picture can be overlaid on video with 128 × 128 24bit bmp format |
| Interface |
|
| Video Output |
1 Vp-p Composite Output (75 Ω/BNC) |
| Ethernet Interface |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
| RS-485 |
RS-485 (half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive) |
| On-Board Storage |
Built-in memory card slot, support microSD/microSDHC/microSDXC/TF card, up to 256 GB |
| Alarm |
1 input, 1 output (max. 24 VDC, 1 A or 110 VAC, 500 mA) |
| Fiber Optical |
1 fiber optical interface, single module, single mode, 20 km transmission distance,
1310 nm (TX) and 1550 nm (RX), 155 Mbps transmission rate
|
| Deep Learning Function |
|
| Hard Hat Detection |
Detects up to 30 human targets simultaneously |
| Supports |
Supports up to 4 shield regions |
| Metadata |
|
| Metadata of road traffic |
Metadata of road traffic is supported |
| General |
|
| Power |
100 to 240 VAC, 0.4 A to 0.17 A, max. 18 W, terminal block;
PoE: 802.3at, 42.5 to 57 V, 0.55 to 0.45 A, max. 18 W
|
| Material |
Stainless steel 316L & anti-corrosion coating |
| Dimension |
352 mm × 200 mm × 214 mm (13.9" × 7.9" × 8.4") |
| Package Dimension |
438 mm × 283 mm × 303 mm (17.2" × 11.1" × 11.9") |
| Weight |
Approx. 14 kg (30.9 lb.) |
| With Package Weight |
Approx. 15 kg (33.1 lb.) |
| Storage Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Startup and Operating Conditions |
-40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing) |
| General Function |
Anti-flicker, 5 streams and 5 custom streams, heartbeat, mirror, privacy mask, pixel counter |
| Heater |
Yes |
| Cable Length |
0.09 m (0.30 ft.) |
