| Performance |
| Dynamic range |
130 dB |
| Languages support |
Multi |
| Number of languages |
33 |
| Built-in light |
Yes |
| Day/night mode |
Yes |
| Infrared (IR) cut-off filter |
Yes |
| Wide Dynamic Range (WDR) |
Yes |
| Connectivity technology |
Wired |
| Placement supported |
Outdoor |
| Type |
IP security camera |
| Design |
| International Protection (IP) code |
IP67 |
| Protection features |
Dust resistant, Water resistant |
| Housing material |
Metal |
| Product colour |
White |
| Mounting type |
Wall |
| Form factor |
Bullet |
| Camera |
| Number of Privacy masking areas |
4 |
| Camera shutter speed |
1/3 - 1/100000 s |
| Pan range |
0 - 360° |
| Tilt angle range |
0 - 90° |
| Lens viewing angle, diagonal |
126.7° |
| Lens viewing angle, vertical |
54.4° |
| Lens viewing angle, horizontal |
104° |
| Angle of rotation |
360° |
| Minimum illumination |
0 lx |
| Image sensor |
| Progressive scan |
Yes |
| Optical sensor size |
25.4 / 1.8 mm (1 / 1.8") |
| Number of sensors |
1 |
| Sensor type |
CMOS |
| Lens system |
| Fixed focal length |
2.8 mm |
| Identify distance |
6 m |
| Maximum aperture number |
1 |
| Fixed focus |
Yes |
| Recognize distance |
12 m |
| Observe distance |
24 m |
| Detect distance |
61 m |
| Number of lenses |
1 |
| Night vision |
| Infra-red wavelength |
850 nm |
| LED type |
IR |
| Night vision distance |
60 m |
| Night vision |
Yes |
| Video |
| Back Light Compensation (BLC) |
Yes |
| Bit rate |
32 Kbps - 8 Mbps |
| Bit rate control |
Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Highlight Compensation (HLC) |
Yes |
| Image quality adjustment |
Brightness, Contrast, Saturation, Sharpness |
| Privacy masking |
Yes |
| Region of Interest (ROI) encoding |
Yes |
| Noise reduction technology |
3D noise reduction |
| Noise reduction |
Yes |
| Video streaming |
Yes |
| Frame rate |
30 fps |
| Supported graphics resolutions |
640 x 360, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2688 x 1520 |
| Video compression formats |
H.264, H.264+, H.265, H.265+, M-JPEG |
| Total megapixels |
4 MP |
| Maximum resolution |
2688 x 1520 pixels |
| Network |
| Client interoperability |
iVMS-4200, Hik-Connect, Hik-Central |
| Live view |
Yes |
| Number of simultaneous live view channels |
6 channels |
| Quality of Service (QoS) support |
Yes |
| Number of users |
32 user(s) |
| User access level |
Administrator, Operator, User |
| Supported network protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP |
| Ethernet interface type |
Fast Ethernet |
| Bluetooth |
No |
| Wi-Fi |
No |
| Ethernet LAN |
Yes |
| Storage |
| Maximum memory card size |
512 GB |
| Compatible memory cards |
MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Card reader integrated |
Yes |
| Built-in HDD |
No |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
1 |
| Security |
| Active tampering alarm |
Yes |
| Audit log |
Yes |
| Automatic Network Replenishment (ANR) |
Yes |
| Digest authentication |
Yes |
| Digital watermark |
Yes |
| HTTPS encryption |
Yes |
| Heartbeat |
Yes |
| Human and vehicle targets classification |
Yes |
| IP address filtering |
Yes |
| Mirror |
Yes |
| Network access storage (NAS) |
Yes |
| Password reset via email |
Yes |
| Pixel counter |
Yes |
| Privacy protection |
Yes |
| Security algorithms |
EAP-LEAP, EAP-MD5, EAP-TLS |
| Video motion detection |
Yes |
| Password protection |
Yes |
| Management features |
| Behavior analysis |
Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection |
| Reset button |
Yes |
| Web-based management |
Yes |
| Power |
| DC output current |
0.66 A |
| DC output voltage |
12 |
| Power consumption (Power over Ethernet (PoE)) |
9 W |
| Power consumption (max) |
8 W |
| Power source type |
DC, PoE |
| Operational conditions |
| Storage relative humidity (H-H) |
0 - 95% |
| Operating relative humidity (H-H) |
0 - 95% |
| Storage temperature (T-T) |
-30 - 60 °C |
| Operating temperature (T-T) |
-30 - 60 °C |
| Weight & dimensions |
| Weight |
1.08 kg |
| Length |
286.7 mm |
| Height |
91.2 mm |
| Width |
93.3 mm |
| Packaging data |
| Package weight |
1.64 kg |
| Package height |
155 mm |
| Package depth |
156 mm |
| Package width |
386 mm |
| Supplier features |
| Manufacturer |
Hikvision |
| Sustainability |
| Sustainability compliance |
Yes |
| Compliance certificates |
BIS, CB, CE, Industry Canada (IC), KC, Low Voltage Directive (LVD), RCM, RoHS, UL |
| Packaging content |
| Number of cameras |
1 |
| Other features |
| Maximum resolution |
2688 x 1520 pixels |
| Technical details |
| Iris |
Yes |
| Lens mount interface |
M16 |
