When you build a control panel, wiring errors and hard-to-replace connections can cause costly downtime. A loose terminal or a wrong node ID can stop a whole line. The Horner HE599CNX100 gives you a solid, removable terminal block that fits on a DIN-rail and lets you set up a CsCAN network fast and safely. It solves the wiring hassle, keeps power stable, and lets you change a whole base without stopping the machine.
Horner HE599CNX100, 16 Base CsCAN 5pin Removable Terminal Block, Expansion Base with Horner
Upgrade your control system with confidence. This product is a 16-base expansion module that uses a 5-pin removable terminal block for CsCAN communication. It is meant for modern OCS controllers that need a reliable, hot-swappable base. If you have ever struggled with fixed wiring or limited node IDs, this base gives you the flexibility to expand and reconfigure without rewiring the whole rack.
Key Features
- Supports 16 bases per system, 8 modules per base.
- 5-pin removable terminal block with M3 screw type.
- DIN-rail mounting for compact panel layout.
- Accepts 14-26 AWG copper wire, 7 mm stripping length.
- Torque rating 0.6 Nm for secure connections.
- Hot-swap capability for the entire base.
- CsCAN communication with CAN bitwise arbitration.
- Steady-state power 400 mA @ 24 VDC, max 11-28 VDC range.
- Digital rotary switches provide node ID configuration.
- Operating temperature 0 C to +55 C, storage -25 C to +70 C.
- CE, UL and C-UL certified for industrial use.
Specifications
| General |
|
| Model |
HE599CNX100 |
| Product Type |
SmartRail I/O – CsCAN Base |
| Communication Type |
CsCAN |
| Compatible Controllers |
Any modern OCS Controller with a built-in CsCAN port |
| Network Architecture |
Daisy-chain or Trunkline-Dropline |
| Hot Swap |
Entire bases may be hot-swapped; individual I/O modules are not hot-swappable |
| Power |
|
| Required Power (Steady State) |
400 mA @ 24 VDC max |
| Primary Power Range |
11–28 VDC |
| Power Supply |
Class 2 Power Supply Only |
| Output Power |
1500 mA @ 5 VDC |
| Power Supplied for I/O Modules |
1500 mA @ 5 VDC maximum |
| Communication |
|
| Data Transmission |
CsCAN |
| Flow Control |
CAN Bitwise Arbitration |
| Connector |
5-pin Removable Terminal Block |
| Node ID Configuration |
Digital Rotary Switches (2) |
| Legal Node IDs |
1 to 79 (Decimal) |
| Inactivity Timeout |
Configurable from Cscape |
| Cscape Version |
9.1 (SP3) or later |
| OCS Firmware Version |
12.75 or later |
| I/O Capacity |
|
| Compatible I/O |
SmartRail I/O |
| Bases Supported (Per System) |
16 |
| Modules Supported (Per Base) |
8 |
| Digital I/O (Max. Per Base) |
256 (Inputs + Outputs) |
| Analog I/O (Max. Per Base) |
32 (Inputs + Outputs) |
| I/O Limitations (Per System) |
2048 Digital Inputs, 2048 Digital Outputs, 512 Analog Inputs, 512 Analog Outputs |
| Mechanical |
|
| Dimensions (H × W × D) |
90 × 45 × 60 mm (3.54 × 1.77 × 2.36 in) |
| Weight |
114 g (4 oz) |
| Mounting |
DIN-Rail |
| Terminal Type |
M3 Screw Type, Removable |
| Optional Terminals |
HE200ACC500 (Spring-Clamp Double Plug), HE200ACC512 (M12 Adapter) |
| Terminal Torque Rating |
0.6 N·m (5.2 in-lb) |
| Accepted Wire Size |
14–26 AWG (Copper) |
| Wire Stripping Length |
7 mm |
| Environmental |
|
| Operating Temperature |
0°C to +55°C |
| Storage Temperature |
-25°C to +70°C |
| Relative Humidity |
5% to 95% Non-Condensing |
| Vibration & Shock |
Per IEC1131-2 |
| Noise Immunity |
Per IEC1131-2, IEC61000-4-2, IEC61000-4-3, IEC61000-4-4 |
| Certifications |
|
| CE |
Yes |
| UL & C-UL |
Class I, Div 2 Groups A, B, C & D |
