| Display |
| Display bezel technology |
Micro-Edge |
| sRGB coverage (typical) |
100% |
| Colour gamut |
100% |
| Colour gamut standard |
sRGB |
| Colour depth |
8 bit |
| Surface hardness |
3H |
| Haze rate |
25% |
| Display diagonal (metric) |
60.5 cm |
| Viewable size diagonal |
6.05 cm |
| Viewable size, vertical |
29.6 cm |
| Viewable size, horizontal |
52.7 cm |
| Vertical scan range |
50 - 100 Hz |
| Horizontal scan range |
30 - 115 kHz |
| Pixel density |
93 ppi |
| Pixel pitch |
0.27 x 0.27 mm |
| Response time (fast) |
5 ms |
| Display number of colours |
16.7 million colours |
| Viewing angle, vertical |
178° |
| Viewing angle, horizontal |
178° |
| Maximum refresh rate |
100 Hz |
| Contrast ratio (dynamic) |
10000000:1 |
| Contrast ratio (typical) |
1500:1 |
| Aspect ratio |
16:9 |
| Supported graphics resolutions |
1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800, 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA) |
| Screen shape |
Flat |
| Anti-glare screen |
Yes |
| Display surface |
Matt |
| Response time measurement type |
GTG (Gray to Gray) |
| Response time |
5 ms |
| Display brightness (typical) |
350 cd/m² |
| Backlight type |
Edge-Lit |
| LED backlight |
Yes |
| Panel type |
IPS |
| HD type |
Full HD |
| Touchscreen |
No |
| Display technology |
LCD |
| Native aspect ratio |
16:9 |
| Display resolution |
1920 x 1080 pixels |
| Display diagonal |
60.5 cm (23.8") |
| Performance |
| Infrared (IR) sensor |
Yes |
| HP segment |
Business |
| Low Blue Light technology |
Yes |
| Flicker-free technology |
Yes |
| Fast charging |
Yes |
| AMD FreeSync |
No |
| NVIDIA G-SYNC |
No |
| Multimedia |
| Built-in microphone |
Yes |
| Megapixel (approx.) |
5 MP |
| Built-in camera |
Yes |
| RMS rated power |
12 W |
| Number of speakers |
4 |
| Built-in speaker(s) |
Yes |
| Design |
| Feet colour |
Silver, Black |
| Detachable stand |
Yes |
| Product colour |
Black |
| Market positioning |
Office |
| Ports & interfaces |
| HDCP |
Yes |
| Built-in KVM switch |
Yes |
| Headphone connectivity |
3.5 mm |
| Headphone outputs |
1 |
| Headphone out |
Yes |
| Audio output |
Yes |
| Audio input |
Yes |
| DisplayPort version |
1.4 |
| DisplayPort out version |
1.4 |
| DisplayPort out quantity |
1 |
| DisplayPorts quantity |
1 |
| HDMI version |
2.0 |
| HDMI ports quantity |
1 |
| HDMI |
Yes |
| USB Power Delivery (USB PD) |
Yes |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| USB Type-A downstream ports quantity |
3 |
| Number of USB Type-B upstream ports quantity |
1 |
| USB hub version |
3.2 Gen 1 (3.1 Gen 1) |
| Built-in USB hub |
Yes |
| Network |
| Remotely operated |
Yes |
| Ethernet LAN |
Yes |
| Ergonomics |
| On Screen Display (OSD) |
Yes |
| Tilt angle range |
-5 - 23° |
| Tilt adjustment |
Yes |
| Swivel angle range |
-45 - 45° |
| Swivelling |
Yes |
| Pivot angle |
-90 - 90° |
| Pivot |
Yes |
| Adjustable height (max) |
15 cm |
| Height adjustment |
Yes |
| Cable lock slot |
Yes |
| Panel mounting interface |
100 x 100 mm |
| VESA mounting |
Yes |
| Power |
| Energy efficiency scale |
A to G |
| Power supply type |
Internal |
| AC input frequency |
50/60 Hz |
| AC input voltage |
100 - 240 V |
| Power consumption (off) |
0.3 W |
| Power consumption (max) |
223 W |
| Power consumption (standby) |
0.5 W |
| Power consumption (typical) |
33 W |
| Energy consumption (SDR) per 1000 hours |
14 kWh |
| Energy efficiency class (HDR) |
D |
| Energy efficiency class (SDR) |
D |
| Operational conditions |
| Operating temperature (T-T) |
5 - 35 °C |
| Storage relative humidity (H-H) |
20 - 80% |
| Operating relative humidity (H-H) |
5 - 95% |
| Operating temperature (T-T) |
5 - 35 °C |
| Weight & dimensions |
| Weight (without stand) |
4.99 kg |
| Height (without stand) |
123.7 mm |
| Depth (without stand) |
18.6 mm |
| Width (without stand) |
212.4 mm |
| Weight (with stand) |
9.5 kg |
| Height (with stand) |
503.2 mm |
| Depth (with stand) |
189.5 mm |
| Width (with stand) |
539.4 mm |
| Packaging data |
| Package type |
Box |
| Package weight |
9.5 kg |
| Package height |
393 mm |
| Package depth |
140 mm |
| Package width |
621 mm |
| Packaging content |
| Bundled software |
HP Display Center; HP Client Management Script Library |
| Quick start guide |
Yes |
| Cables included |
AC, DisplayPort, USB Type-A to USB Type-B |
| Sustainability |
| Sustainability certificates |
ENERGY STAR |
| Other features |
| Disclaimer |
<sup>[1]</sup> HP Series 5 Pro monitor or additional monitor sold separately.<br><sup>[2]</sup> For KVM compatibility, if connected PCs do not have USB-C port, user will need a USB-B to A cable.<br><sup>[3]</sup> Recycled plastic is expressed as a percentage of the total weight plastic. Post-consumer recycled is based on the definition set in the EPEAT standard for computers, IEEE 1680.1-2018 standard.<br><sup>[4]</sup> Recycled metal is expressed as a percentage of the total weight of the metal according to ISO 14021 definitions for metal parts over 25 grams.<br><sup>[5]</sup> Percentage of recycled glass in the monitor panel varies by product. Recycled glass is expressed as a percentage of the total weight of the glass.<br><sup>[7]</sup> All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary, either higher or lower.<br><sup>[8]</sup> HP's Progressive White Balance feature is designed to calibrate 100% full white on HP Series 5 Pro monitors. This adjustment is intended to align the white point more closely among various HP Series 5 Pro monitors. However, due to the nature of monitors, perceptible differences in the white color may still occur when the monitors are viewed from varying angles.<br><sup>[9]</sup> 100Hz refresh rate supported on host PCs with DisplayPort™ 1.2 or higher. Host PC may affect the refresh rate combinations of monitors 1 and 2. Refresh rates can be user enabled in PC settings.<br><sup>[10]</sup> AC Power cable, DisplayPort™ 1.4 cable, and USB 3.0 A-B cable, and USB 3.1 C-C cable included. All other cables sold separately.<br><sup>[11]</sup> Ergonomic Setup Guide is available through HP Display Center. Host PC requires Windows 10 or higher. HP Display Center is available on the Microsoft store.<br><sup>[12]</sup> Host PC requires Windows 10 or higher. HP Display Center is available for download on the Microsoft store for Windows or support.hp.com for Windows and MacOS.<br>Technical specification disclaimers:<br>All performance specifications represent the typical specifications provided by HP's component manufacturers, actual performance may vary either higher or lower.<br>DisplayPort™ 1.4 or HDMI 2.0 required to drive panel at its native resolution. The video card of the connected PC must be capable of supporting 1920 x 1080 at 60 Hz with 8 bit color using one DisplayPort™, HDMI. The video card of the connected PC must be capable of supporting 1920 x 1080 and include one DisplayPort™ or one HDMI outputs to drive the monitor at the Preferred Mode.<br>Number of colors through A-FRC technology.<br>Included cables may vary by country.<br>100% outer box packaging and corrugated cushions made from sustainably sourced certified and recycled fibers.<br>ITE Derived Closed Loop Plastic percentage is based on the definition set in the IEEE 1680.1-2018 standard.<br>Ocean Bound plastic is based on the definition set by the UL2809 standard.<br>Recycled metal is expressed as a percentage of the total weight of the metal according to ISO 14021 definitions for metal parts over 25 grams.<br>Percentage of recycled glass in the monitor panel varies by product. Recycled glass is expressed as a percentage of the total weight of the glass.<br>Host PC requires Windows 10 and above. HP Display Center is available on the Microsoft store.<br>The Client Management Script Library must be downloaded to the connected PC to run CMSL commands. Some limitations may apply to legacy displays. Visit support.hp.com to download HP CMSL.<br>Lock sold separately.<br>EPEAT registered where applicable. EPEAT registration varies by country. See www.epeat.net for registration status by country. Based on US EPEAT registration according to IEEE 1680.1-2018 EPEAT. Status varies by country. Visit www.epeat.net for more information.<br>Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or separately purchased hardware, drivers, software or BIOS update to take full advantage of Windows functionality. Windows is automatically updated and enabled. High speed internet and Microsoft account required. ISP fees may apply and additional requirements may apply over time for updates. See http://www.windows.com. |
| UNSPSC-code |
43211902 |
| Certification |
Australian-New Zealand MEPS; BIS; BSMI; CB; CCC; CE; CECP; CEL; CEL Grade 1; cTUVus; EAC; FCC; ICES; ISO 9241-307; KC; KCC; NOM; PSB; RCM; SEPA; TUV-S; VCCI; Vietnam MEPS; WEEE; ISC; California Energy Commission (CEC); UAE; TGM; Ukraine certificates; TÜV Flicker free certified; NRCS; PSE; GS; Ukraine EE; TÜV Low Blue Light Hardware Solution certified; Korea MEPS; Australian-New Zealand DoC; EMF |
| Ethernet LAN (RJ-45) ports |
1 |
| Compliance certificates |
BIS, BSMI, CB, CCC, CE, CECP, CEL, EAC, Federal Communications Commission (FCC), ICES, KC, KCC, Norma Oficial Mexicana (NOM), PSE, RCM, VCCI, WEEE, cTUVus |
| Manufacturer warranty |
HP three-year limited warranty |
| Package weight |
9.5 kg |
| Weight |
9.5 kg |
| Country of origin |
China, Thailand |
| Brand-specific features |
| HP GTIN (EAN/UPC) |
198122901920 |
| Technical details |
| General Product Safety Regulation (GPSR) URL |
https://support.hp.com/us-en/document/ish_6126692-6126777-16?openCLC=true |
