| Processor |
| Processor codename |
Ice Lake |
| Thermal Design Power (TDP) |
205 W |
| Processor cache |
39 MB |
| Processor boost frequency |
3.6 GHz |
| Processor operating modes |
64-bit |
| System bus rate |
11.2 GT/s |
| Processor threads |
36 |
| Component for |
Server/workstation |
| Cooler included |
No |
| Box |
No |
| Processor lithography |
10 nm |
| Processor socket |
LGA 4189 |
| Processor cores |
18 |
| Processor base frequency |
3 GHz |
| Processor model |
6354 |
| Processor generation |
3rd Generation Intel® Xeon® Scalable |
| Processor family |
Intel® Xeon® Gold |
| Processor manufacturer |
Intel |
| Memory |
| ECC |
Yes |
| Memory channels |
Octa-channel |
| Memory types supported by processor |
DDR4-SDRAM |
| Maximum internal memory supported by processor |
6 TB |
| Graphics |
| Discrete graphics card model |
Not available |
| On-board graphics card model |
Not available |
| Discrete graphics card |
No |
| On-board graphics card |
No |
| Features |
| Commodity Classification Automated Tracking System (CCATS) |
G178966 |
| Export Control Classification Number (ECCN) |
5A992CN3 |
| Scalability |
2S |
| Supported instruction sets |
SSE4.2, AVX, AVX 2.0, AVX-512 |
| PCI Express slots version |
4.0 |
| Maximum number of PCI Express lanes |
64 |
| Market segment |
Server |
| Execute Disable Bit |
Yes |
| Processor special features |
| AVX-512 Fused Multiply-Add (FMA) units |
2 |
| Intel 64 |
Yes |
| Intel Software Guard Extensions (Intel SGX) |
Yes |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Intel Virtualization Technology (VT-x) |
Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU |
Yes |
| Intel® Optane™ DC Persistent Memory Supported |
Yes |
| Intel® Resource Director Technology (Intel® RDT) |
Yes |
| Intel® Run Sure Technology |
Yes |
| Intel® Volume Management Device (VMD) |
Yes |
| Mode-based Execute Control (MBE) |
Yes |
| Intel® Crypto Acceleration |
Yes |
| Intel® Platform Firmware Resilience Support |
Yes |
| Maximum Enclave Size Support for Intel® SGX |
64 GB |
| Intel® Total Memory Encryption |
Yes |
| Intel® Transactional Synchronization Extensions |
Yes |
| Intel Trusted Execution Technology |
Yes |
| Intel® AES New Instructions (Intel® AES-NI) |
Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) |
Yes |
| Intel® Speed Shift Technology |
Yes |
| Intel® Turbo Boost Technology |
2.0 |
| Operational conditions |
| Tcase |
77 °C |
| Technical details |
| Launch date |
Q2'21 |
| Memory speed (max) |
3200 MHz |
| Number of UPI links |
3 |
| Status |
Launched |
| Target market |
Cloud Computing |
| Processor cache |
39 MB |
| Supported memory types |
DDR4-SDRAM |
| Weight & dimensions |
| Processor package size |
77.5 x 56.5 mm |
| Other features |
| Maximum internal memory |
6 TB |
| Maximum internal memory |
6 TB |
