IEI Puzzle-3034 Intel ATOM C3758R, 8GB RAM, 8 x 2.5 GbE Network Gateway
IEI Puzzle-3034 Intel ATOM C3758R, 8GB RAM, 8 x 2.5 GbE Network Gateway
IEI Puzzle-3034 Intel ATOM C3758R, 8GB RAM, 8 x 2.5 GbE Network Gateway
IEI Puzzle-3034 Intel ATOM C3758R, 8GB RAM, 8 x 2.5 GbE Network Gateway
IEI Puzzle-3034 Intel ATOM C3758R, 8GB RAM, 8 x 2.5 GbE Network Gateway
IEI Puzzle-3034 Intel ATOM C3758R, 8GB RAM, 8 x 2.5 GbE Network Gateway
IEI Puzzle-3034 Intel ATOM C3758R, 8GB RAM, 8 x 2.5 GbE Network Gateway

IEI Puzzle-3034 Intel ATOM C3758R, 8GB RAM, 8 x 2.5 GbE Network Gateway

Buy 5 or More Units - Unlock Priority Discounts!
Buy 20 or More Units - Get Exclusive Volume Discounts!


Also Support: Google & Apple Pay

Are you a reseller or placing a large order?
We're happy to offer Special Pricing tailored to your needs.
Click "Request Quote" or email us at [email protected] to get your best price today!

Add to Wishlist

Compare

Product Code: GTWY-090

MPN #: PUZZLE-3034-C3758R/8G-R10

Specifications:

Form Factor
Form Factor Desktop
System
CPU Intel® Atom® C3758R 8C/8T (16M Cache, 2.4 GHz)
Chipset Intel® Denverton-R
Memory DDR4 2400MHz Non-ECC UDIMM
Memory Max. Up to 64GB
Cooling method / System Fan 2 x Cooling Fans
Physical Characteristics
Dimensions (LxWxH) (mm) 285 x 236.6 x 46.65
Storage
Storage eMMC : 64GB
I/O Interface
Ethernet 4 x SFP+ : 10 GbE, 8 x LAN : 2.5 GbE RJ45
I/O Interface 1 x Console port(s) : RJ45, 2 x USB 3.0
Expansion 4 x M.2(NGFF) -, 1 x 2242 B-Key M.2 slot for M2 SATA, 1 x 3052 B-Key M.2 slot + SIM Card Socket for 5G/LTE Card, 2 x 2280 M-Key M.2 slots for NVMe
Power
Input 100 V ~ 240 V
Power Supply Open Frame DPS-60AP-5D; Vin : 90 ~ 264VAC; 70W
Environment
Operating Temperature 0°C ~ 40°C (32°F ~ 104°F)
Storage Temperature -10°C ~ 50°C
Humidity 5% ~ 90% non-condensing
Certifications
Safety & EMC CE, FCC, VCCI, RCM
OS Compatible
OS Compatible Linux Ubuntu 18.04
Ordering Information
PUZZLE-3034-C3758R/8G-R10 Desktop Network Appliance with Intel® ATOM® C3758R Processor , 1 x 8GB RAM , 8 x 2.5GbE , 4 x 10 GbE, eMMC 64GB, 1 x console port, 4x M.2 slot , RoHS.
Package Contents
Package Contents 1 x Power cord, 2 x Rack mounting ears, 6 x Screw for rack mounting ears
