Intel Core i3-8100H 8th Gen Processor (4 Cores, 6MB Smart Cache, 3.00GHz)

When an embedded or mobile computing system needs a compact processor with four physical cores, integrated graphics, ECC memory support, and a 45W thermal design, a mobile-class processor can provide a practical balance between processing capability and system size. The Intel Core i3-8100H is designed for embedded and mobile platforms that require consistent processing performance without the higher requirements of larger desktop processors.

Intel Core i3-8100H 8th Gen Processor (4 Cores, 6MB Smart Cache, 3.00GHz)

The Intel Core i3-8100H is an 8th Generation Intel Core i3 processor based on the Coffee Lake product family. It features 4 cores and 4 threads with a 3.00 GHz processor base frequency, providing a straightforward processing platform for embedded computing, industrial systems, compact workstations, and other applications that need reliable multi-core CPU performance.

The processor includes 6 MB of Intel Smart Cache and supports DDR4-2666 memory with up to 64 GB of maximum memory capacity. It provides two memory channels and supports ECC memory, making it suitable for compatible platforms where memory reliability is important.

For graphics and display workloads, the processor integrates Intel UHD Graphics 630. The integrated graphics support up to three displays and provide eDP, DisplayPort, HDMI, and DVI graphics outputs through the compatible system platform. It supports 4K output, with DisplayPort supporting up to 4096x2304 at 60Hz.

The Core i3-8100H operates with a 45 W TDP and supports a configurable 35 W TDP-down mode with a 2.60 GHz configurable TDP-down base frequency. Its 14 nm lithography and FCBGA1440 package make it intended for systems where the processor is integrated directly into the platform rather than installed as a conventional desktop socketed CPU.

The processor also includes Intel technologies such as Speed Shift, Quick Sync Video, AES New Instructions, Virtualization Technology (VT-x), VT-d, Secure Key, Boot Guard, and thermal monitoring technologies. With embedded options available and an Embedded Broad Market Commercial temperature use condition, the processor can be used in compatible embedded platforms requiring integrated computing, graphics, memory, and expansion capabilities.

Key features

• 8th Generation Intel® Core™ i3 Processor
• 4 cores and 4 threads
• 3.00 GHz processor base frequency
• 6 MB Intel® Smart Cache
• Supports up to 64 GB DDR4-2666 memory
• Intel® UHD Graphics 630 with 4K support
• 45 W TDP with configurable 35 W TDP-down

Specifications
