Intel® i5-1135G7 8 LAN Dual Display GPIO Wi-Fi/4G Fanless Security Gateway Appliance
Designed for industrial automation, cybersecurity, and secure networking environments, this embedded fanless security gateway appliance is powered by the 11th Gen Intel® Core™ i5-1135G7 quad-core processor, delivering speeds up to 4.20 GHz. With Intel® AES-NI for high-speed data encryption and decryption, and Intel® SGX for hardware-enforced trusted execution, it offers robust security capabilities ideal for critical applications.
This compact and durable system supports up to 64GB DDR4 memory (2x32GB SODIMM) and dual storage options—mSATA SSD and 2.5" SATA SSD/HDD—making it both high-performing and versatile. It features 6x Intel® I210-AT and 2 x Intel i225-V 2.5 Gigabit LAN (supporting Wake-on-LAN and PXE boot), along with dual COM ports (DB9 RS232 and RJ45 console) for seamless communication and connectivity.
Additional I/O includes:
-
4x USB 3.0 and 2x USB 2.0 ports
-
Dual display support via VGA and HDMI
-
10-pin 4-way In/Out GPIO Phoenix Terminal
-
Wi-Fi and 4G LTE (optional) (WIFI and LAN8 are two choices, default is LAN8)
Housed in a completely fanless aluminium alloy chassis, it ensures silent operation, excellent heat dissipation, and long-term reliability in dust-prone or industrial environments. With support for Windows, Linux, and various firewall systems, this appliance is a powerful, energy-efficient solution for secure and high-performance edge networking.
Features:
Intel® Core™ i5-1135G7 (4 Core, up to 4.20 GHz)
Support up to 64GB (2x32GB) SODIMM DDR4 Memory
Support Dual Storage (mSATA & 2.5" SATA SSD/HDD)
6x Intel® I210-AT Gigabit LAN
2 x Intel i225-V 2.5 Gigabit LAN
RS232 COM & RJ45 Console
Dual VGA & HDMI Display
10pin 4 Way In/Out GPIO Phoenix Terminal
Support Wi-Fi & WWAN 4G LTE
4x USB 3.0 & 2x USB 2.0 Ports
Energy Efficient, Low Power Consumption
Support Windows, Linux & Firewalls etc.
Perfect for Industrial Automation, Firewall, Cyber Security etc.
Specifications:
| Model Number |
MNHO-142 |
| CPU |
Intel® Core™ i5-1135G7 |
| # of Cores |
4 |
| Max. Turbo Frequency |
Up to 4.20 GHz |
| Memory |
2 x SO-DIMM DDR4 up to 32GB |
| Non-ECC |
| Storage |
1 x mSATA3.0 SSD |
| 1 x 2.5" SATA SSD/HDD |
| Expansion Slots |
1 x mSATA (For mSATA SSD) |
| 1 x Full Size mini PCIe (For WiFi/4G Module) |
| 1 x 2.5" SATA Slot (For 2.5" SSD/HDD) |
| 1 x Internal USB (For USB Wi-Fi) |
| I/O Interfaces |
6 x Intel i210-AT Gigabit LAN
2 x Intel i225-V 2.5 Gigabit LAN
(Support Network Wake-up/PXE) |
| 1 x RS232 DB9 COM |
| 1 x RJ45 Console |
| 1 x HDMI |
| 1 x VGA |
| 4 x USB 3.0 |
| 3 x USB 2.0 |
| 1 x 12V DC-In (5.5*2.5mm Socket) |
| 1 x Audio In & Out (ALC662 6-Channel HD) |
| 1 x 12pin 4 Way In/Out GPIO (Phoenix Terminal) |
| 1 x SIM Slot |
| 2 x Antenna Ports |
| 1 x Reset Switch |
| 1 x Power Switch |
| 1 x AC Loss Power on Switch |
| Operating Systems |
Support Windows & Linux |
| Working Environment |
-10°C ~ 35°C (Operating Temperature) |
| -20°C ~ 70°C (Storage Temperature) |
| 5% - 95% non-condensing (Relative Humidity) |
| 0.5g rms/5-500HZ/random/operating (Vibration) |
| Others |
CE, UKCA, FCC and RoHS Compliant |
| Support (L256 Segments, 0~255 Sec) (Watchdog) |
| Aluminium Alloy FANLESS, Silent |
| 235mm*192mm*57mm (L*W*H) |
| 1 x Mini PC, 1 x Power Adapter, 1 x Power Cord |
