Enhanced Power Loss Data Protection
Enhanced Power Loss Data Protection prepares the SSD for unexpected system power loss by minimizing data in transition in temporary buffers, and uses on-board power-loss protection capacitance to provide enough energy for the SSD firmware to move data from the transfer buffer and other temporary buffers to the NAND, thus protecting system and user data.
Hardware Encryption
Hardware encryption is data encryption done at the drive level. This is used to ensure that the data stored on the drive is secured from unwanted intrusion.
High Endurance Technology (HET)
High Endurance Technology (HET) in SSD's combines Intel® NAND Flash Memory silicon enhancements and SSD system management techniques to help extend the endurance of the SSD. Endurance is defined as the amount of data that can be written to an SSD during its lifetime.
Temperature Monitoring and Logging
Temperature Monitoring and Logging uses an internal temperature sensor to monitor and log airflow and device internal temperature. The logged results can be accessed using the SMART command.
End-to-End Data Protection
End-to-End Data Protection ensures integrity of stored data from the computer to the SSD and back.
Specifications
| Features |
| Temperature monitoring and logging |
Yes |
| SSD ARK ID |
140103 |
| Market segment |
Server |
| Mean time between failures (MTBF) |
2000000 h |
| Uncorrectable Bit Error Rate (UBER) |
< 1 per 10^17 bits read |
| SSD temperature monitoring |
Yes |
| Enhanced Power Loss Data Protection technology |
Yes |
| End-to-End Data Protection |
Yes |
| Write latency |
18 µs |
| Read latency |
77 µs |
| Sequential latency - write (up to) |
18 µs |
| Sequential latency - read (up to) |
12 µs |
| Random latency - write (up to) |
20 µs |
| Random latency - read (up to) |
95 µs |
| Random write (100% span) |
199000 IOPS |
| Random read (100% span) |
643000 IOPS |
| Random write (4KB) |
199000 IOPS |
| Random read (4KB) |
643000 IOPS |
| Write speed |
2080 MB/s |
| Read speed |
3200 MB/s |
| Security algorithms |
256-bit AES |
| Hardware encryption |
Yes |
| Component for |
Server/workstation |
| Memory type |
TLC 3D NAND |
| NVMe |
Yes |
| Interface |
PCI Express 3.1 |
| SSD form factor |
U.2 |
| SSD capacity |
1.6 TB |
| Power |
| Power consumption (idle) |
5 W |
| Power consumption (write) |
14 W |
| Power consumption (read) |
14 W |
| Brand-specific features |
| Intel® Smart Response Technology |
No |
| Intel High Endurance Technology (HET) |
Yes |
| Intel® Rapid Start Technology |
No |
| Intel® Remote Secure Erase |
No |
| Weight & dimensions |
| Weight |
139 g |
| Width |
15 mm |
| Operational conditions |
| Operating / non-operating shock |
1000G (0.5ms) |
| Non-operating shock |
100 G |
| Operating shock |
1000 G |
| Non-operating vibration |
3.13 G |
| Operating vibration |
2.17 G |
| Maximum operating temperature |
55 °C |
| Minimum operating temperature |
0 °C |
| Operating temperature (T-T) |
0 - 55 °C |
| Other features |
| Product codename |
Cliffdale Refresh |
| Product series |
Intel® SSD DC P4610 Series |
| Product family |
Data center SSD |
| Drive capacity |
1.6 TB |
| Last change |
63903513 |
| Launch date |
Q2'18 |
| Power consumption (active) |
14 W |
| SSD endurance rating |
12.25PBW |
| SSD hardware encryption |
AES 256 bit |
| SSD power consumption (active) |
14W |
| SSD power consumption (idle) |
5W |
| SSD shock |
1000G (0.5ms) |
| SSD weight |
139 g |
| Sequential reading |
3200 MB/s |
| Sequential writing speed |
2080 MB/s |
| Status |
Launched |
| Operating temperature (T-T) |
0 - 55 °C |
