iWARP/RDMA
iWARP delivers converged, low-latency fabric services to data centers through Remote Direct Memory Access (RDMA) over Ethernet. The key iWARP components that deliver low-latency are Kernel Bypass, Direct Data Placement, and Transport Acceleration.
Intel® Data Direct I/O Technology
Intel® Data Direct I/O Technology is a platform technology that improves I/O data processing efficiency for data delivery and data consumption from I/O devices. With Intel DDIO, Intel® Server Adapters and controllers talk directly to the processor cache without a detour via system memory, reducing latency, increasing system I/O bandwidth, and reducing power consumption.
PCI-SIG* SR-IOV Capable
Single-Root I/O Virtualization (SR-IOV) involves natively (directly) sharing a single I/O resource between multiple virtual machines. SR-IOV provides a mechanism by which a Single Root Function (for example a single Ethernet Port) can appear to be multiple separate physical devices.
Flexible Port Partitioning
Flexible Port Partitioning (FPP) technology utilizes industry standard PCI SIG SR-IOV to efficiently divide your physical Ethernet device into multiple virtual devices, providing Quality of Service by ensuring each process is assigned to a Virtual Function and is provided a fair share of the bandwidth.
Virtual Machine Device Queues (VMDq)
Virtual Machine Device Queues (VMDq) is a technology designed to offload some of the switching done in the VMM (Virtual Machine Monitor) to networking hardware specifically designed for this function. VMDq drastically reduces overhead associated with I/O switching in the VMM which greatly improves throughput and overall system performance
Specifications
| Ports & interfaces |
| PCI version |
3.0 |
| Ethernet LAN (RJ-45) ports |
4 |
| Interface |
Ethernet |
| Host interface |
PCI Express |
| Connectivity technology |
Wired |
| Network |
| LAN controller |
Intel X710-TM4 |
| Maximum operating distance |
100 m |
| Ethernet LAN data rates |
100,1000,2500,5000,10000 Mbit/s |
| Ethernet interface type |
10 Gigabit Ethernet |
| Ethernet LAN |
Yes |
| Networking standards |
IEEE 1588, IEEE 802.3az |
| Maximum data transfer rate |
10000 Mbit/s |
| Design |
| LED indicators |
Yes |
| Product colour |
Black, Green, Grey |
| Component for |
Server |
| Internal |
Yes |
| System requirements |
| Compatible operating systems |
https://www.intel.com/content/www/us/en/support/articles/000025890/network-and-i-o/ethernet-products.html |
| Operational conditions |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating temperature (T-T) |
0 - 55 °C |
| Weight & dimensions |
| Depth |
69 mm |
| Width |
167 mm |
| Other features |
| Product series |
700 Series Network Adapters (up to 40GbE) |
| Launch date |
Q3'20 |
| Network interface card cable medium |
Copper |
| Network interface card type |
Server |
| Product brief URL |
https://www.intel.com/content/www/us/en/products/docs/network-io/ethernet/network-adapters/ethernet-adapter-x710-t2l-t4l-brief.html |
| Status |
Launched |
| Storage Over Ethernet |
iSCSI, NFS |
| Target market |
Artificial Intelligence, High Performance Computing |
| Bracket height |
Low-Profile (LP) / Full-Height (FH) |
| Cabling type |
RJ45 Category 6, Category 6A, Category 5e up to 100m |
| Commodity Classification Automated Tracking System (CCATS) |
NA |
| Controller type |
Intel® Ethernet Controller X710-TM4 |
| Export Control Classification Number (ECCN) |
5A991 |
| Intel Data Direct I/O Technology |
Yes |
| Intel Flexible Port Partitioning |
Yes |
| Intel Virtual Machine Device Queues (VMDq) |
Yes |
| Intel Virtualization Technology for Connectivity (VT-c) |
Yes |
| Intelligent Offloads |
Yes |
| Interface type |
PCIe v3.0 (8.0GT/s) |
| On-chip QoS and Traffic Management |
Yes |
| Operating temperature (T-T) |
0 - 55 °C |
| PCI-SIG* SR-IOV Capable |
Yes |
| Processor family |
700 Network Adapters (up to 40GbE)-700 Network Adapters (up to 40GbE) |
| Product type |
Network Interface Card |
| Speed & slot width |
8.0 GT/s, x8 Lane |
| iWARP/RDMA |
No |
| Market segment |
Server |
| Cable type |
RJ45 Category 6, Category 6A, Category 5e up to 100m |
