| Processor |
| Processor ARK ID |
236183 |
| Processor codename |
Raptor Lake |
| Maximum number of DMI lanes |
8 |
| Stepping |
B0 |
| Thermal Design Power (TDP) |
80 W |
| Processor cache |
24 MB |
| Processor boost frequency |
5.2 GHz |
| Performance cores |
8 |
| Processor operating modes |
64-bit |
| System bus rate |
16 GT/s |
| Processor threads |
16 |
| Box |
Yes |
| Processor socket |
LGA 1700 |
| Processor cores |
8 |
| Processor base frequency |
2.8 GHz |
| Processor model |
E-2478 |
| Processor family |
Intel Xeon E |
| Processor manufacturer |
Intel |
| Memory |
| ECC |
Yes |
| Memory channels |
Dual-channel |
| Memory types supported by processor |
DDR5-SDRAM |
| Maximum internal memory supported by processor |
128 GB |
| Graphics |
| Discrete graphics card model |
Not available |
| On-board graphics card model |
Not available |
| Discrete graphics card |
No |
| On-board graphics card |
No |
| Features |
| Commodity Classification Automated Tracking System (CCATS) |
740.17B1 |
| Export Control Classification Number (ECCN) |
5A992C |
| CPU configuration (max) |
1 |
| Embedded options available |
No |
| Scalability |
1S |
| Supported instruction sets |
AVX 2.0, SSE4.1, SSE4.2 |
| PCI Express configurations |
2x8+1x4, 1x16+1x4 |
| PCI Express slots version |
5.0 |
| Maximum number of PCI Express lanes |
20 |
| Use conditions |
Server/Enterprise |
| Market segment |
Server |
| Execute Disable Bit |
Yes |
| Idle States |
Yes |
| Thermal Monitoring Technologies |
Yes |
| Processor special features |
| Intel® Total Memory Encryption - Multi Key |
Yes |
| Intel 64 |
Yes |
| Intel Turbo Boost Max Technology 3.0 |
Yes |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Intel Virtualization Technology (VT-x) |
Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Intel® Boot Guard |
Yes |
| Intel® OS Guard |
Yes |
| Intel® Optane™ DC Persistent Memory Supported |
No |
| Intel® Secure Key |
Yes |
| Intel® Virtualization Technology with Redirect Protection (VT-rp) |
Yes |
| Microprocessor PCIe Revision |
Gen 5 |
| Mode-based Execute Control (MBE) |
Yes |
| Intel® Total Memory Encryption |
Yes |
| Intel® Transactional Synchronization Extensions |
No |
| Intel® Turbo Boost Max Technology 3.0 frequency |
5.2 GHz |
| Intel® Turbo Boost Technology 2.0 frequency |
5.2 GHz |
| Enhanced Intel SpeedStep Technology |
Yes |
| Intel Trusted Execution Technology |
Yes |
| Intel® AES New Instructions (Intel® AES-NI) |
Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) |
Yes |
| Intel® Turbo Boost Technology |
2.0 |
| Operational conditions |
| Tjunction |
100 °C |
| Technical details |
| Servicing status |
Baseline Servicing |
| Launch date |
Q4'23 |
| Status |
Launched |
| Processor cache |
24 MB |
| Other features |
| Maximum internal memory |
128 GB |
| Maximum internal memory |
128 GB |
